UQFPH-M-200 - 200Amp Circuit Breaker

UQFPH-M-200 - 200Amp Circuit Breaker

The Milbank UQFPH-M-200 Circuit Breaker is a powerful and dependable solution for metering applications, providing superior protection and reliability in high-capacity systems. With a 200Amp rating and a 240V AC voltage capacity, this thermal magnetic breaker is designed to meet the demands of modern residential, commercial, and light industrial applications. Its 22,000A interrupting capacity ensures safe operation even in high fault current conditions.

Key Features and Benefits:

• High Interrupting Capacity: Rated at 22kAIC, it efficiently handles fault conditions to protect electrical systems and equipment.
• Thermal Magnetic Trip Mechanism: Combines overload and short-circuit protection, ensuring robust and precise operation.
• Durable Construction: Built with non-metallic materials for enhanced durability and resistance to environmental conditions.
• Load Side Threaded Tap Tangs: Facilitates secure and reliable load-side connections for flexible installations.
• Plug-In Design: Simplifies installation and maintenance while ensuring a stable and secure connection.

Technical Specifications:

• Type: Current Interrupting Device
• Voltage Rating: 240V AC
• Amperage: 200Amp
• Frequency: 60Hz
• Poles: 2
• Phase: Single-phase
• Frame Type: F-Frame
• Trip Type: Thermal Magnetic
• Interrupting Capacity: 22kAIC
• Material: Non-Metallic
• Dimensions: Height: 6.063 in, Length: 3.281 in, Width: 3 in
• Operating Temperature: 40å¡C
• Connection: Bus to Lug
• Actuator: Lever
• Auxiliary Contacts: Not included

Material Compliance and Certifications:

• The UQFPH-M-200 is UL Listed and meets national safety standards, ensuring dependable performance in various utility-approved metering setups. Prior to installation, consult local utility and electrical inspectors to ensure compliance with specific requirements. Installation must be performed by a licensed electrician in accordance with all applicable codes and regulations.

Suitability:

• This 200Amp circuit breaker is ideal for residential, commercial, and light industrial settings requiring high interrupting capacity and secure connections. Its compatibility with metering applications and durable design make it a reliable choice for demanding environments.
