TJJ436150 - 150Amp Circuit Breaker

TJJ436150 - 150 Amp Circuit Breaker

When you’re maintaining an existing electrical distribution system, compatibility and dependable protection matter; the TJJ436150 molded case circuit breaker is built for exactly that purpose. Designed as part of the well-known Q-Line family, this 3-pole, 150-amp circuit breaker delivers the form, fit, and function needed for a wide range of commercial and industrial applications. Whether it’s installed during a facility upgrade, a service replacement, or ongoing maintenance work, this breaker is designed to integrate with compatible systems without unnecessary complications.

The TJJ436150 uses a thermal magnetic trip unit with an internal common trip, helping protect equipment and conductors from overloads and short circuits while ensuring all poles disconnect together during a fault condition. Its bolt-on mounting design provides a secure connection within compatible panelboards and switchgear, while the included load-side lugs simplify field installation. Because it carries HACR certification, this breaker is also suitable for heating, air conditioning, and refrigeration equipment applications where reliable circuit protection is essential.

Built to handle demanding electrical environments, the TJJ436150 offers interrupting capacities of 22 kA at 600 VAC, 30 kA at 480 VAC, and 42 kA at 240 VAC. That combination of ratings makes it a practical choice for facilities operating across different voltage systems. From manufacturing plants and commercial buildings to HVAC distribution systems, this breaker continues to be used in applications where long-lasting electrical protection and equipment compatibility are important.

Key Features and Benefits

• 150 Amp Rating: Designed for commercial and industrial power distribution applications.
• 3-Pole Configuration: Ideal for protecting three-phase electrical systems.
• Thermal Magnetic Trip Unit: Responds to both overload and short-circuit conditions.
• Internal Common Trip: Disconnects all poles simultaneously during a fault event.
• Bolt-On Design: Supports secure installation in compatible electrical equipment.
• Q-Line Compatibility: Designed for use with matching Q-Line systems and panelboards.
• HACR Rated: Suitable for HVAC and refrigeration-related applications.
• Includes Load-Side Lugs: Helps reduce installation time and simplifies wiring.
• Built to Last: Manufactured for dependable service in demanding environments.


Technical Specifications

• Part Number: TJJ436150

• Type: TJJ

• Product Category: Molded Case Circuit Breaker

• Poles: 3

• Amperes: 150A

• Trip Unit: Thermal Magnetic

• Trip Configuration: Internal Common Trip

• Mounting Style: Bolt-On

• Series: Q-Line

• A.I.C. Rating @ 240VAC: 42kA

• A.I.C. Rating @ 480VAC: 30kA

• A.I.C. Rating @ 600VAC: 22kA

• HACR Rated: Yes

• Included Accessories: Load-Side Lugs

• Dimensions:
  • Height: 10.13 in.
  • Width: 8.25 in.
  • Depth: 3.81 in.

Material Compliance and Certifications

• HACR Rated: Rated for heating, air conditioning, and refrigeration equipment applications.
• Commercial and Industrial Use: Manufactured for use in commercial and industrial electrical distribution systems.
• Thermal Magnetic Protection: Supports established electrical safety requirements.
• Q-Line Compatibility: Designed for compatibility with applicable Q-Line electrical equipment.


Where It Works Best

• The TJJ436150 is commonly used in commercial facilities, industrial plants, manufacturing operations, HVAC systems, mechanical equipment rooms, electrical distribution panels, three-phase power systems, and replacement applications for compatible Q-Line equipment. For electricians, maintenance teams, and facility managers working with existing infrastructure, the TJJ436150 provides a dependable solution for maintaining safe and consistent circuit protection in compatible electrical systems.
