THQP250 - 50A Circuit Breaker

THQP250 50A Circuit Breaker

The THQP250 Circuit Breaker is a top-tier, thermal-magnetic breaker designed to provide robust protection and space-saving efficiency for both residential and commercial electrical systems. As part of the Q Line series, this breaker is half the width of standard breakers, allowing for the use of smaller load centers and maximizing savings in both space and money. Ideal for cost- and quality-conscious contractors and homeowners, the THQP250 breaker maintains GE's renowned flexibility and performance standards. Featuring a 2-pole design, a 50 AMP rating, and an interrupting capacity of 10kAIC, this breaker ensures reliable protection and operational efficiency.

Key Features and Benefits:

• Space-Saving Design: Half the width of standard breakers, allowing for smaller load centers and maximizing space efficiency.
• High-Quality Protection: Combines thermal and magnetic trip elements for quick and reliable response to electrical faults, ensuring maximum safety.
• Cost-Effective: Provides significant savings in space and money without sacrificing flexibility and performance.
• Easy Installation and Maintenance: Plug-in design simplifies installation in Q Line load centers and lighting panels, with easy-to-spot trip indication for convenient maintenance.
• Versatile Applications: Suitable for a wide range of residential and commercial environments, ensuring reliable performance and safety.

Technical Specifications:

• Amperage: 50 A
• Poles: 2
• Voltage Rating: 120/240 V
• Interrupting Capacity: 10 kAIC
• Trip Style: Non-Interchangeable
• Frame Type: Q-Line
• System Voltage: 120 Vac, 120/240 Vac
• Wire Range (Cu/Al): 8-4 kcmil / 8-4 kcmil
• Special Markings: HACR (Heating, Air Conditioning, and Refrigeration)
• Suitable for Reverse Feed: Yes

Material Compliance and Certifications:

• UL File #E11592: Certified to meet stringent UL standards for safety and performance.
• GSA Compliance: Yes

Suitability:

• The THQP250 Circuit Breaker is ideal for a variety of applications, from residential homes to commercial buildings, where space-saving design and reliable overcurrent protection are essential. Its compact size, robust performance, and ease of installation make it a versatile and indispensable component for modern electrical systems, providing the safety and reliability you need.
