THQP230 - 30Amp Circuit Breaker

THQP230 - 30 Amp Circuit Breaker

The THQP230 2-Pole 30 Amp Circuit Breaker is a compact, space-saving solution designed for dependable circuit protection in your residential and light commercial electrical systems. Built as part of the trusted Q-Line family, this THQP series breaker features a thin profile that helps maximize panel space without sacrificing performance. Its plug-on design allows for quick installation, while the internal common trip mechanism provides added safety by simultaneously disconnecting both poles during overloads or short circuits. Rated at 10k A.I.C. at 120VAC and HACR rated for heating, air conditioning, and refrigeration applications, the THQP230 is well-suited for protecting branch circuits that require consistent, reliable operation. Whether you're upgrading an older panel or replacing a worn breaker, this molded case circuit breaker delivers the performance electricians and maintenance professionals expect in demanding environments.

Key Features and Benefits

• Thin "space-saving" THQP design: Helps maximize load center capacity.
• 2-pole configuration with internal common trip: Provides enhanced protection by simultaneously disconnecting both poles during overloads or short circuits.
• 30-amp rating: Ideal for a wide range of residential and commercial branch circuits.
• Plug-on mounting: Simplifies installation and replacement.
• HACR Rated: Suitable for HVAC and refrigeration equipment applications.
• Molded case construction: Designed for dependable long-term use.
• Compatible with Q-Line panel systems: Built for use with compatible Q-Line load centers and panelboards.


Technical Specifications

• Part Number: THQP230

• Type: THQP

• Poles: 2

• Amperage: 30A

• A.I.C. Rating: 10k

• Voltage Rating: 120VAC

• Mounting Style: Plug-On

• Circuit Breaker Style: Molded Case Circuit Breaker

• Trip Type: Internal Common Trip

• Dimensions:
  • Height: 3.25 in.
  • Width: 1.0 in.
  • Depth: 2.56 in.

Material Compliance and Certifications

• HACR Rated: Rated for heating, air conditioning, and refrigeration applications.
• Industry Standards: Manufactured to meet industry standards for molded case circuit breakers.
• Panel Compatibility: Designed for use in compatible Q-Line load centers and panelboards.


Where It Works Best

• The THQP230 circuit breaker is an excellent fit for residential electrical panels, apartment buildings, office spaces, retail environments, and light commercial facilities where conserving panel space is important. Its slim profile makes it especially useful in crowded load centers. At the same time, the 30-amp, 2-pole configuration is commonly used for HVAC systems, air conditioning units, water heaters, and other 240V branch-circuit applications requiring reliable dual-pole protection.
