THQP130 - 30Amp Circuit Breaker

THQP130 - 30 Amp Circuit Breaker

The THQP130 30 Amp Single-Pole Circuit Breaker is a smart choice for protecting your residential and light commercial electrical systems, especially when space inside the panel is limited. Designed as part of the trusted Q-Line family, this THQP series breaker features a thin, space-saving profile that allows more circuits to fit into your load center without sacrificing performance or safety. With a 10k A.I.C. rating at 120 VAC, this molded-case circuit breaker helps protect electrical systems against overloads and short circuits while maintaining reliable operation in demanding environments. Its plug-on design also makes installation straightforward for qualified professionals, helping you to reduce downtime during upgrades, replacements, or maintenance work. HACR-rated and engineered for dependable protection, the THQP130 is commonly used in HVAC applications, branch circuit protection, lighting systems, and general power distribution where compact efficiency matters.

Key Features and Benefits

• 30 Amp Single-Pole Protection: Provides reliable branch circuit protection for residential and light commercial electrical systems.
• THQP “THIN” Design: Helps maximize panel space utilization by allowing more circuits to fit into compatible load centers.
• Plug-On Mounting Style: Supports quick and efficient installation for qualified professionals during upgrades, replacements, or maintenance work.
• Trusted Q-Line Family: Part of the Q-Line breaker family commonly used in residential and commercial applications.
• HACR Rated: Approved for use with heating, air conditioning, and refrigeration equipment.
• Molded Case Construction: Built for long-term electrical protection against overloads and short circuits.
• Compact Footprint: Ideal for crowded load centers and panelboards where conserving space is important.


Technical Specifications

• Part Number: THQP130

• Type: THQP

• Poles: 1

• Amperes: 30A

• Voltage Rating: 120VAC

• A.I.C. Rating: 10kA @ 120VAC

• Mounting Style: Plug-On

• Breaker Style: Thin / Space-Saving

• Construction Type: Molded Case Circuit Breaker

• Dimensions:
  • Height: 3.25 in.
  • Width: 0.5 in.
  • Depth: 2.56 in.

Material Compliance and Certifications

• HACR Rated: Approved for HVAC and refrigeration applications.
• Industry Standards: Manufactured to meet industry standards for molded case circuit breaker performance and electrical protection.
• Compatibility: Designed for use in compatible Q-Line load centers and panelboards.


Where It Works Best

• The THQP130 circuit breaker is well-suited for residential breaker panels, apartment buildings, office spaces, retail environments, and light commercial electrical systems where conserving panel space is important. Its slim design makes it especially useful in load centers that require additional circuits without expanding the enclosure. This breaker is also a practical solution for HVAC systems, lighting circuits, receptacle protection, and general-purpose branch-circuit applications requiring dependable 30-amp protection.
