THQMV150D - 150Amp Circuit Breaker

THQMV150D - 150 Amp Circuit Breaker

The THQMV150D circuit breaker is a 2-pole, 150-amp plug-on breaker designed for dependable overcurrent protection in your commercial and industrial electrical distribution systems. Built for use in compatible panelboards and switchboard applications, this Type THQMV breaker features a 22k A.I.C. rating at 120/240VAC and includes a mounting kit for secure installation. Its compact footprint simplifies integration into existing electrical systems where space and compatibility matter. Designed to deliver reliable circuit protection under demanding operating conditions, the THQMV150D is commonly used in facilities that require consistent power distribution and equipment protection. With durable construction and proven performance, this breaker is built to last while helping you to maintain safe electrical operation.

Key Features and Benefits

• 150 amp, 2-pole circuit breaker for branch and feeder protection
• Type THQMV design for compatible legacy electrical systems
• Plug-on configuration with included mounting kit for straightforward installation
• 22k A.I.C. rating at 120/240VAC for dependable interrupting capability
• Compact dimensions help maximize panel space efficiency
• Built for long-term use in commercial and industrial environments
• Designed to help protect electrical equipment from overloads and short circuits

Technical Specifications

• Part Number: THQMV150D

• Type: THQMV

• Poles: 2

• Amperes: 150A

• Voltage Rating: 120/240VAC

• A.I.C. Rating: 22kA @ 120/240VAC

• Mounting Style: Plug-On Circuit Breaker with Mounting Kit

• Dimensions:
  • Height: 5.25 in.
  • Width: 8.0 in.
  • Depth: 3.75 in.

Material Compliance and Certifications

• Industry Standards: The THQMV150D circuit breaker is manufactured for use in accordance with applicable industry electrical standards and is intended for installation in properly rated electrical distribution equipment.
• Installation Notice: Always verify compatibility and local code requirements before installation or replacement.


Where It Works Best

• The THQMV150D is well-suited for commercial buildings, industrial facilities, manufacturing operations, and electrical distribution systems requiring a 150-amp, 2-pole breaker solution. It is commonly used in panelboards and switchboards where reliable overcurrent protection and compatibility with existing equipment are essential.
