THQL2170 - 70Amp Circuit Breaker

THQL2170 - 70 Amp Circuit Breaker

The THQL2170 is a 70 amp, 2 pole circuit breaker used in 120/240VAC electrical distribution systems. It is part of the THQL Q-Line series and features a plug-on connection for installation in compatible panelboards and load centers.

This breaker is designed to provide overcurrent protection by disconnecting power when an overload or short circuit occurs. The 2-pole configuration is commonly used for larger loads that require 240 volts, including HVAC equipment, air conditioners, compressors, and other high-demand electrical circuits.

The THQL2170 has an interrupting rating of 10kA at 120/240VAC and is HACR rated for heating, air conditioning, and refrigeration applications. Its molded case design helps you to protect internal components during normal operation.

Key Features and Benefits

• 70 amp current rating
• 2 pole breaker
• THQL type
• Q-Line series
• Plug-on mounting design
• 120/240VAC rating
• 10kA interrupting capacity
• HACR rated
• Molded case construction
• Provides overload and short-circuit protection

Technical Specifications

• Part Number: THQL2170
• Type: THQL
• Series: Q-Line
• Poles: 2
• Amperage: 70 Amps
• Voltage Rating: 120/240VAC
• A.I.C. Rating: 10kA @ 120/240VAC
• Mounting Style: Plug-On
• HACR Rated: Yes
• Dimensions:
  • Height: 3.31 in.
  • Width: 2.00 in.
  • Depth: 2.81 in.

Material Compliance and Certifications

• HACR Rated
• Molded Case Circuit Breaker
• Manufactured for use in compatible Q-Line electrical distribution equipment
• Install according to applicable electrical codes and manufacturer requirements

Where It Works Best

• The THQL2170 is commonly used in residential and commercial electrical systems requiring a 70 amp, 2-pole breaker. Typical applications include air conditioning units, HVAC equipment, refrigeration systems, subpanels, workshops, and other 120/240VAC branch circuits.
