THQL2140GF1 - 40Amp Circuit Breaker

THQL2140GF1 - 40 Amp Circuit Breaker

The THQL2140GF1 is a 40-amp, 2-pole ground fault circuit breaker used in compatible Q-Line load centers and panelboards. Rated for 120/240 VAC with a 10kA interrupting capacity, it helps you protect electrical circuits from overloads, short circuits, and ground fault conditions.

This breaker uses a plug-on design and fits applications where a THQL-series device is specified. Its HACR rating makes it suitable for use with heating, air conditioning, and refrigeration equipment. The molded case construction is built for everyday service and is intended to provide long-lasting protection in residential, commercial, and light industrial electrical systems.

Whether you're replacing an existing breaker or maintaining an installed panel, the THQL2140GF1 offers the form, fit, and function required for compatible equipment without requiring modifications to the original setup.

Key Features and Benefits

• 40 Amp Current Rating: Rated for 40 amps and designed for applications requiring this level of branch circuit protection.
• 2-Pole Configuration: Provides protection for 120/240 VAC circuits using a 2-pole breaker design.
• Ground Fault Protection: Helps protect electrical circuits from ground fault conditions in addition to overloads and short circuits.
• Plug-On Installation: Uses a plug-on mounting design for installation in compatible Q-Line load centers and panelboards.
• HACR Rated: Suitable for use with heating, air conditioning, and refrigeration equipment.
• Molded Case Construction: Built for everyday service and intended to provide long-lasting protection in residential, commercial, and light industrial electrical systems.


Technical Specifications

• Part Number: THQL2140GF1

• Type: THQL

• Poles: 2

• Amperage: 40A

• Voltage Rating: 120/240 VAC

• Interrupting Rating: 10kA @ 120/240 VAC

• Mounting Style: Plug-On

• Series: Q-Line

• HACR Rated: Yes

• Dimensions:
  • Height: 3.31 in.
  • Width: 2.00 in.
  • Depth: 2.81 in.

Material Compliance and Certifications

• HACR Rated: Approved for use with heating, air conditioning, and refrigeration equipment.
• Compatible Equipment: Manufactured for use in compatible Q-Line electrical distribution equipment.
• Molded Case Construction: Molded case circuit breaker construction.
• Application Compliance: Intended for applications requiring ground fault protection and branch circuit protection.


Where It Works Best

• The THQL2140GF1 is commonly used in residential and commercial electrical systems where a 40-amp, 2-pole breaker with ground fault protection is required. Typical applications include HVAC equipment, air conditioning systems, refrigeration equipment, subpanels, and other 120/240 VAC branch circuits installed in compatible Q-Line panelboards and load centers.
