THQL2135 - 35Amp Circuit Breaker

THQL2135 - 35 Amp Circuit Breaker

The THQL2135 35 Amp 2-Pole Circuit Breaker is a dependable molded case circuit breaker designed to provide reliable overcurrent and short-circuit protection in your residential, commercial, and light industrial electrical distribution systems. As part of the widely used THQL Q-Line series, this breaker features a convenient plug-on design that allows for straightforward installation in compatible load centers and panelboards. With a 35-amp rating, 2-pole configuration, and 120/240VAC operating voltage, the THQL2135 helps you safeguard electrical circuits and connected equipment while supporting consistent system performance.

Built for applications that require dependable circuit protection, the THQL2135 combines proven thermal-magnetic tripping technology with a compact footprint, making it a practical choice for branch circuit protection. Its HACR rating also makes it suitable for use in heating, air conditioning, and refrigeration applications where reliable protection is essential. Whether used in new installations, panel upgrades, or maintenance projects, this breaker delivers the performance electrical professionals expect from a trusted Q-Line circuit protection solution.

Key Features and Benefits

• 35 Amp Continuous Current Rating: For dependable branch circuit protection.
• 2-Pole Design: Provides protection for 120/240VAC electrical systems.
• 10kA Interrupting Capacity (A.I.C.): Helps safely interrupt fault currents.
• THQL Q-Line Series Compatibility: Designed for compatibility with approved Q-Line load centers and panelboards.
• Plug-On Mounting Style: Enables fast and efficient installation.
• Thermal-Magnetic Trip Mechanism: Helps protect against overloads and short circuits.
• HACR Rated: For use in heating, air conditioning, and refrigeration applications.
• Compact Molded Case Construction: Helps maximize panel space while maintaining reliable protection.
• Versatile Application: Suitable for residential, commercial, and light industrial electrical systems.


Technical Specifications

• Part Number: THQL2135

• Type: THQL

• Circuit Breaker Style: Molded Case Circuit Breaker

• Series: Q-Line

• Mounting: Plug-On

• Poles: 2

• Amperage Rating: 35 Amps

• Voltage Rating: 120/240VAC

• Interrupting Capacity (A.I.C.): 10kA @ 120/240VAC

• HACR Rated: Yes

• Dimensions:
  • Height: 3.31 in.
  • Width: 2.00 in.
  • Depth: 2.81 in.

Material Compliance and Certifications

• Industry Standards: The THQL2135 is manufactured to meet applicable industry standards for molded case circuit breakers and is designed for use in approved electrical distribution equipment.
• Installation Requirements: Installation should always be performed in accordance with local electrical codes, applicable regulations, and manufacturer requirements to ensure safe and proper operation.


Where It Works Best

• The THQL2135 is well-suited for protecting branch circuits in residential load centers and service panels, commercial electrical distribution systems, HVAC and refrigeration equipment requiring HACR-rated protection, lighting circuits, general-purpose power distribution applications, and electrical panel upgrades, maintenance projects, and replacement installations.
• Its combination of a 35-amp rating, dual-pole protection, and plug-on convenience makes it an excellent choice for applications requiring dependable protection in 120/240VAC electrical systems.
