THQL2130 - 30Amp Circuit Breaker

THQL2130 - 30 Amp Circuit Breaker

The THQL2130 circuit breaker is a 30-amp, 2-pole, molded-case circuit breaker designed to provide dependable overcurrent and short-circuit protection for your residential, commercial, and light industrial electrical systems. As part of the trusted THQL Q-Line series, this plug-on breaker delivers reliable performance while helping you protect electrical equipment, branch circuits, and connected loads from potentially damaging electrical faults. Its compact design allows for efficient installation in compatible load centers and panelboards, making it a practical solution for new construction, system upgrades, maintenance projects, and replacement applications. Built for consistent operation under demanding electrical conditions, the THQL2130 combines safety, convenience, and long-term durability in a space-saving package.

Key Features and Benefits

• 30 amp current rating: For a variety of branch circuit applications.
• 2-pole configuration: For 120/240VAC systems.
• 10kA interrupting capacity (AIC): Helps protect against fault currents.
• Plug-on design: Enables fast and straightforward installation.
• Molded case construction: Offers dependable electrical protection.
• HACR rated: For use in heating, air conditioning, and refrigeration applications.
• Part of the Q-Line family: Known for compatibility and reliable performance.
• Compact footprint: Helps maximize panel space utilization.
• Designed to protect wiring and connected equipment: From overloads and short circuits.


Technical Specifications

• Part Number: THQL2130

• Type: THQL

• Current Rating: 30 Amps

• Poles: 2

• Voltage Rating: 120/240 VAC

• Interrupting Capacity: 10kA

• Mounting Style: Plug-On

• Construction: Molded Case Circuit Breaker

• HACR Rated: Yes

• Series: Q-Line

• Dimensions:
  • Height: 3.31 in.
  • Width: 2.00 in.
  • Depth: 2.81 in.

Material Compliance and Certifications

• Industry Standards: The THQL2130 is manufactured to meet applicable industry standards for molded case circuit breakers and is designed for use in approved electrical distribution systems.
• HACR Rating: Its HACR rating supports applications involving heating, air conditioning, and refrigeration equipment that require code-compliant circuit protection. Always verify local code requirements and equipment compatibility before installation.


Where It Works Best

• The THQL2130 is well-suited for residential service panels, commercial buildings, HVAC equipment circuits, workshops, garages, small industrial facilities, and general-purpose branch circuit protection applications. Its 30-amp rating and 2-pole configuration make it a common choice for 240-volt loads, including air conditioning equipment, water heaters, compressors, and other electrical systems that require reliable dual-pole circuit protection.
