THQL2115 - 15Amp Circuit Breaker

THQL2115 - 15 Amp Circuit Breaker

The THQL2115 is a 2-pole, 15-amp circuit breaker designed for use in compatible Q-Line load centers and panelboards. Rated for 120/240 VAC systems, it protects against overloads and short circuits while helping you maintain the safe operation of connected electrical equipment and branch circuits.

This breaker features a plug-on design that allows for straightforward installation and replacement in approved panels. With a 10 kA interrupting rating, it is suitable for many residential and commercial electrical distribution applications requiring reliable circuit protection. The THQL2115 is also HACR rated, making it an appropriate choice for certain heating, air conditioning, and refrigeration circuits.

Whether you're replacing an existing breaker or servicing an electrical panel, the THQL2115 offers a practical solution for protecting 120/240V circuits without taking up unnecessary panel space.

Key Features and Benefits

• 15 amp rating
• 2-pole configuration
• 120/240VAC operation
• 10kA interrupting capacity
• Plug-on mounting design
• Part of the THQL Q-Line series
• HACR rated
• Molded case construction
• Suitable for residential and commercial applications

Technical Specifications

• Part Number: THQL2115

• Type: THQL

• Series: Q-Line

• Poles: 2

• Amperage: 15 Amps

• Voltage Rating: 120/240VAC

• Interrupting Capacity: 10kA

• Mounting Style: Plug-On

• HACR Rated: Yes

• Dimensions:
  • Height: 3.31 in.
  • Width: 2.00 in.
  • Depth: 2.81 in.

Material Compliance and Certifications

• HACR Rated: HACR Rated
• Installation Requirements: Manufactured for use in compatible electrical distribution systems
• Code Compliance: Install according to applicable electrical codes and manufacturer requirements.


Where It Works Best

• The THQL2115 is commonly used in residential service panels, commercial buildings, light industrial facilities, HVAC equipment circuits, refrigeration systems, and general branch circuit protection applications requiring a 2-pole 15-amp breaker.
