THQD22125 - 125A Circuit Breaker

THQD22125 125A Circuit Breaker

Unlock superior safety and efficiency with the THQD22125 Circuit Breaker, meticulously engineered for demanding electrical systems. This robust 2-pole circuit breaker, featuring a 240V rating and a substantial 125 amp capacity, ensures a high interrupting capacity of 22K IC, guaranteeing reliable protection against electrical faults.

Key Features and Benefits:

• High Interrupting Capacity: With a 22K AIC rating, this breaker is designed to handle severe short-circuit conditions, providing enhanced safety and system protection.
• Dual Voltage Compatibility: This model operates efficiently across multiple voltages (120 Vac, 120/240 Vac, 240 Vac), making it versatile for various electrical applications.
• Thermal Magnetic Protection: Incorporates both thermal and magnetic trip actions to deliver precise protection by detecting and interrupting both overload and short-circuit faults.
• Durable Construction: Equipped with Cu/Al line and load lugs and a robust Q-Line frame type, it ensures long-lasting performance and ease of installation.
• Suitability for Reverse Feed: Offers flexible installation options, supporting reverse feed use for diverse application requirements.

Technical Specifications:

• Amperage: 125 A
• System Voltage: 120 Vac, 120/240 Vac, 240 Vac
• Trip Function: LI, ensuring low-intensity trip settings for circuit protection.
• Lugs: TCAL25, compatible with a wide range of wire sizes for easy integration.

Material Compliance and Certifications:

• UL File Number: E11592 certifies compliance with stringent safety standards, affirming the breaker‰۪s reliability and quality.
• Wire Range: Accepts (2) 1-300, accommodating a broad spectrum of wire sizes, which aids in flexible installation setups.

Suitability and Installation:

• This circuit breaker is perfectly suited for commercial and residential installations that demand high capacity and dependable trip characteristics. It can be integrated into power distribution setups in both new constructions and system upgrades, ensuring seamless compatibility with existing infrastructure.

By choosing the THQD22125, you invest in a reliable, efficient, and versatile circuit protection solution, enhancing the safety and operational integrity of your electrical installations. Whether upgrading an old panel or setting up a new system, this breaker provides the performance and peace of mind needed in any electrical infrastructure.
