THQC32080WL - 80Amp Circuit Breaker

THQC32080WL - 80 Amp Circuit Breaker

The THQC32080WL is an 80 amp, 3-pole circuit breaker used for overcurrent protection in your three-phase electrical systems. It features an internal common trip design, which causes all poles to open when a fault condition is detected on any pole. The breaker uses a cable-in/cable-out (lug-lug) connection arrangement and is rated for 240VAC applications with a 10kA interrupting capacity. As part of the THQC Q-Line series, this molded case circuit breaker is commonly installed in commercial and industrial distribution equipment where three-phase circuit protection is required. Its compact size makes it suitable for your panelboard and power distribution applications where space may be limited.

Key Features and Benefits

• 80 amp rating: 80 amp rating.
• 3-pole configuration: 3-pole configuration.
• Internal common trip operation: Internal common trip operation.
• 10kAIC rating at 240VAC: 10kAIC rating at 240VAC.
• Cable-in/cable-out (lug-lug) connections: Cable-in/cable-out (lug-lug) connections.
• HACR rated: HACR rated.
• THQC Q-Line design: THQC Q-Line design.
• Molded case construction: Molded case construction.


Technical Specifications

• Part Number: THQC32080WL

• Type: THQC

• Amperage: 80A

• Poles: 3

• Voltage Rating: 240VAC

• Interrupting Capacity: 10kAIC

• Connection Type: Lug-Lug

• Trip Type: Internal Common Trip

• HACR Rated: Yes

• Construction: Molded Case Circuit Breaker

• Dimensions:
  • Height: 3.94 in.
  • Width: 3.00 in.
  • Depth: 2.63 in.

Material Compliance and Certifications

• HACR Rated: This circuit breaker is HACR rated for use in approved heating, ventilation, air conditioning, and refrigeration applications.
• Installation Verification: Always verify compatibility with the intended equipment and installation requirements before use.


Where It Works Best

• The THQC32080WL is commonly used in commercial buildings, industrial facilities, HVAC equipment, distribution panels, motor circuits, and other three-phase systems requiring an 80 amp circuit breaker with common-trip protection.
