THQC32020WL - 20Amp Circuit Breaker

THQC32020WL - 20 Amp Circuit Breaker

The THQC32020WL is a 20-amp, 3-pole molded case circuit breaker designed for protecting your three-phase electrical circuits from overloads and short circuits. Featuring an internal common trip mechanism, all three poles open simultaneously when a fault is detected, helping you maintain safe operation of connected equipment and electrical systems. This breaker belongs to the THQC Q-Line series and utilizes a cable-in/cable-out (lug-lug) connection design for straightforward installation in compatible distribution equipment. With a 10kA interrupting rating at 240VAC, it is built to handle fault conditions commonly encountered in commercial and industrial power systems. The breaker is also HACR rated, making it suitable for heating, air conditioning, and refrigeration applications. Its compact molded case construction helps you to conserve valuable panel space while providing reliable circuit protection. Whether installed in a panelboard, HVAC system, machinery circuit, or other three-phase application, the THQC32020WL delivers dependable performance where consistent electrical protection is required.

Key Features and Benefits

• 20 amp current rating: 20 amp current rating.
• 3-pole configuration for three-phase circuits: 3-pole configuration for three-phase circuits.
• Internal common trip operation: Internal common trip operation.
• 10kA interrupting capacity at 240VAC: 10kA interrupting capacity at 240VAC.
• Cable-in/cable-out (lug-lug) connections: Cable-in/cable-out (lug-lug) connections.
• HACR rated: HACR rated.
• Compact molded case design: Compact molded case design.
• Part of the THQC Q-Line product family: Part of the THQC Q-Line product family.
• Helps protect electrical equipment from overloads and short-circuit faults: Helps protect electrical equipment from overloads and short-circuit faults.


Technical Specifications

• Part Number: THQC32020WL

• Type: THQC

• Poles: 3

• Amperage: 20A

• Voltage Rating: 240VAC

• Interrupting Rating: 10kAIC

• Trip Mechanism: Internal Common Trip

• Connection Style: Cable-in/Cable-out (Lug-Lug)

• HACR Rated: Yes

• Construction: Molded Case Circuit Breaker

• Dimensions:
  • Height: 3.94 in.
  • Width: 3.00 in.
  • Depth: 2.63 in.

Material Compliance and Certifications

• HACR Rated: HACR rated for heating, air conditioning, and refrigeration applications.
• Electrical Distribution Systems: Manufactured for use in compatible electrical distribution systems.
• Industry Requirements: Designed to meet applicable industry requirements for molded case circuit breakers. Installation should be performed in accordance with local electrical codes and equipment specifications.


Where It Works Best

• The THQC32020WL is commonly used in commercial facilities, industrial buildings, HVAC equipment, refrigeration systems, motor loads, and other three-phase power distribution applications that require 20 amp circuit protection. Its common trip design makes it especially useful where coordinated disconnection of all phases is required.
