THQC32015WL - 15Amp Circuit Breaker

THQC32015WL - 15 Amp Circuit Breaker

The THQC32015WL is a 15-amp, 3-pole molded case circuit breaker used in applications that require protection for three-phase circuits operating at up to 240VAC. As a member of the THQC Q-Line family, it features an internal common trip mechanism that opens all poles together if an overload or short circuit occurs. This breaker is equipped with a cable-in/cable-out lug configuration, making it a practical choice for your installations where direct conductor termination is required. With a 10kA interrupting rating, the THQC32015WL is built to handle available fault currents commonly found in commercial and light industrial electrical systems. Its HACR rating also makes it suitable for heating, ventilation, air conditioning, and refrigeration equipment. The compact size helps you to conserve valuable panel space while still delivering the protection needed for branch circuits, equipment feeds, and other three-phase loads. For electricians and maintenance professionals working with compatible Q-Line equipment, the THQC32015WL offers a straightforward solution when adding new circuits, replacing an existing breaker, or maintaining electrical distribution systems.

Key Features and Benefits

• 15 amp current rating: Provides protection for circuits requiring a 15-amp breaker.
• 3-pole configuration: Designed for three-phase circuit applications.
• Internal common trip operation: Opens all poles simultaneously if an overload or short circuit occurs.
• 10kA interrupting capacity at 240VAC: Built to handle available fault currents commonly found in commercial and light industrial electrical systems.
• Cable-in/cable-out (lug-lug) connections: Allows direct conductor termination for practical installation.
• HACR rated: Suitable for heating, ventilation, air conditioning, and refrigeration equipment.
• Molded case construction: Provides durable circuit protection.
• Compact design for efficient panel utilization: Helps conserve valuable panel space.
• Compatible with Q-Line applications: Designed for use with compatible Q-Line equipment.


Technical Specifications

• Part Number: THQC32015WL

• Type: THQC

• Series: Q-Line

• Amperage: 15 Amps

• Poles: 3

• Voltage Rating: 240VAC

• Interrupting Rating: 10kAIC

• Trip Function: Internal Common Trip

• Connection Style: Cable-In/Cable-Out (Lug-Lug)

• Construction: Molded Case Circuit Breaker

• HACR Rated: Yes

• Dimensions:
  • Height: 3.94 in.
  • Width: 3.00 in.
  • Depth: 2.63 in.

Material Compliance and Certifications

• HACR Rated: HACR rated for approved HVAC and refrigeration applications.
• Molded Case Construction: Molded case circuit breaker construction.
• Installation Requirements: Intended for installation in accordance with applicable electrical codes and manufacturer requirements.
• Equipment Compatibility: Suitable for use in properly rated electrical distribution equipment.


Where It Works Best

• The THQC32015WL is commonly found in commercial electrical panels, three-phase branch circuits, HVAC and refrigeration equipment, light industrial facilities, equipment distribution circuits, and building electrical systems requiring a 15-amp, 3-pole breaker. Its combination of common trip protection, lug-lug connections, and compact dimensions makes it a practical choice for a variety of three-phase power distribution applications.
