THQC2160WL - 60Amp Circuit Breaker

THQC2160WL - 60 Amp Circuit Breaker

The THQC2160WL is a 60-amp, 2-pole circuit breaker designed for protecting your 120/240VAC electrical systems from overloads and short circuits. As part of the THQC Q-Line family, it features an internal common trip mechanism that disconnects both poles simultaneously when a fault occurs. This helps you protect connected equipment while supporting safe operation of the electrical system.

Built with a cable-in/cable-out (lug-lug) connection design, the THQC2160WL allows for straightforward conductor termination in compatible installations. Its compact molded case construction makes it a practical choice for panelboards and load centers where dependable circuit protection is required without taking up unnecessary space. The breaker is also HACR rated, making it suitable for many heating, ventilation, air conditioning, and refrigeration applications.

Whether you're replacing an existing breaker or maintaining an electrical distribution system, the THQC2160WL provides the performance needed for a wide range of residential and commercial applications.

Key Features and Benefits

• 60 amp current rating: Provides reliable circuit protection for applications requiring a 60-amp breaker.
• 2-pole configuration for 120/240VAC circuits: Designed for use in 120/240VAC electrical systems requiring two-pole protection.
• Internal common trip design: Disconnects both poles simultaneously when a fault occurs to support safe system operation.
• 10kA interrupting rating at 120/240VAC: Delivers fault interruption capability for compatible electrical systems.
• Cable-in/cable-out (lug-lug) connections: Allows for straightforward conductor termination in compatible installations.
• HACR rated for HVAC and refrigeration equipment: Suitable for many heating, ventilation, air conditioning, and refrigeration applications.
• Compact molded case construction: Provides dependable circuit protection in panelboards and load centers without taking up unnecessary space.
• Compatible with Q-Line applications: Designed for use in compatible Q-Line electrical distribution equipment.


Technical Specifications

• Part Number: THQC2160WL

• Type: THQC

• Poles: 2

• Amperage: 60A

• Voltage Rating: 120/240VAC

• Interrupting Rating: 10kA

• Connection Type: Lug-Lug (Cable-In/Cable-Out)

• Trip Mechanism: Internal Common Trip

• HACR Rated: Yes

• Dimensions:
  • Height: 3.94 in.
  • Width: 2.00 in.
  • Depth: 2.63 in.

Material Compliance and Certifications

• HACR Rated: Approved for use in many heating, ventilation, air conditioning, and refrigeration applications.
• Molded Case Circuit Breaker Construction: Built with molded case construction for dependable circuit protection.
• Compatible Equipment: Designed for use in compatible electrical distribution equipment.
• Installation Requirements: Installation should comply with applicable electrical codes and manufacturer requirements.


Where It Works Best

• The THQC2160WL is commonly used in residential and commercial electrical systems requiring a 60-amp, 2-pole breaker. Typical applications include HVAC equipment, air conditioning units, refrigeration systems, branch circuit protection, panelboard installations, and general power distribution. Its common-trip operation makes it a good fit for circuits that require simultaneous disconnection of both poles during fault conditions.
