THQC1125WL - 25Amp Circuit Breaker

THQC1125WL - 25 Amp Circuit Breaker

When your dependable circuit protection matters, the THQC1125WL 25 Amp 1-Pole Circuit Breaker delivers the performance needed to help keep electrical systems operating safely and efficiently. Designed as part of the proven THQC Q-Line series, this molded-case circuit breaker provides reliable overcurrent and short-circuit protection for 120 VAC branch circuits in residential, commercial, and light industrial applications.

Built with a convenient cable-in/cable-out (lug-lug) configuration, the THQC1125WL makes conductor termination straightforward while maintaining a secure electrical connection. Its 25-amp rating makes it an excellent choice for dedicated circuits serving lighting, receptacles, HVAC equipment, refrigeration systems, and other electrical loads that require dependable protection. With a 10kA interrupting capacity at 120VAC, this breaker is engineered to respond quickly to fault conditions, helping you to protect valuable equipment and wiring from damage.

The HACR rating adds another layer of versatility, making the THQC1125WL suitable for heating, air conditioning, and refrigeration applications where code-compliant circuit protection is essential. Whether you're maintaining an existing electrical system, replacing a faulty breaker, or supporting a new installation, this breaker offers the trusted performance professionals look for when reliability is a top priority.

Key Features and Benefits

• 25 Amp Protection: Ideal for branch circuits requiring reliable 25A overcurrent protection.
• Single-Pole Configuration: Designed for 120VAC electrical circuits.
• 10kA Interrupting Capacity: Helps safely clear fault currents before they can cause damage.
• THQC Q-Line Design: Compatible with applicable Q-Line panelboard and load center applications.
• Lug-Lug Construction: Cable-in/cable-out terminals provide secure, efficient conductor connections.
• HACR Rated: Suitable for HVAC and refrigeration equipment applications.
• Molded Case Design: Built for consistent performance and long service life in demanding electrical environments.
• Space-Saving Footprint: Compact dimensions help maximize panel space.


Technical Specifications

• Part Number: THQC1125WL

• Type: THQC

• Circuit Breaker Type: Molded Case Circuit Breaker

• Poles: 1

• Amperage Rating: 25 Amps

• Voltage Rating: 120VAC

• Interrupting Capacity (A.I.C.): 10kA @ 120VAC

• Connection Style: Cable-In/Cable-Out (Lug-Lug)

• HACR Rated: Yes

• Product Line: Q-Line

• Dimensions:
  • Height: 3.94 in.
  • Width: 1.00 in.
  • Depth: 2.63 in.

Material Compliance and Certifications

• HACR Rated: The THQC1125WL is HACR rated, making it suitable for applications involving heating, air conditioning, and refrigeration equipment.
• Installation Requirements: All installations should be performed in accordance with applicable electrical codes, manufacturer requirements, and local regulations to ensure safe and proper operation.


Where It Works Best

• The THQC1125WL is commonly used in residential load centers, commercial electrical distribution panels, HVAC equipment circuits, refrigeration systems, lighting and receptacle branch circuits, electrical maintenance and retrofit projects, and general-purpose 120VAC power distribution applications. Its combination of dependable protection, compact size, and versatile application support makes the THQC1125WL a practical solution for electricians, contractors, facility managers, and maintenance professionals seeking reliable circuit protection.
