THQB2140GF - 40Amp Circuit Breaker

THQB2140GF - 40 Amp Circuit Breaker

The THQB2140GF is a 40-amp, 2-pole bolt-on circuit breaker designed for you to use in compatible Q-Line panelboards operating on 120/240VAC systems. With a 10kA interrupting rating, this molded-case breaker helps you to protect electrical circuits from overcurrent damage while providing ground-fault protection where required. Its bolt-on construction allows for a secure connection within the panel, making it a practical choice for maintaining existing electrical distribution equipment.

This breaker is commonly found in commercial and industrial installations, including applications involving HVAC and refrigeration equipment. Because it is HACR rated, it can be used on approved heating, air conditioning, and refrigeration circuits. The THQB2140GF is built for long service life and is intended to match the form, fit, and function requirements of compatible systems already in operation.

Key Features and Benefits

• 40 Amp current rating
• 2-pole configuration
• Ground fault protection
• 10kA interrupting capacity at 120/240VAC
• Bolt-on mounting design
• Compatible with designated Q-Line panelboards
• HACR rated for approved HVAC and refrigeration applications
• Molded case construction is built for everyday electrical distribution use


Technical Specifications

• Part Number: THQB2140GF

• Type: THQB

• Poles: 2

• Amperage: 40A

• Voltage: 120/240VAC

• A.I.C. Rating: 10kA @ 120/240VAC

• Mounting: Bolt-On

• Product Line: Q-Line

• HACR Rated: Yes

• Dimensions:
  • Height: 3.5 in.
  • Width: 2.0 in.
  • Depth: 2.81 in.

Material Compliance and Certifications

• HACR rated
• Molded case circuit breaker construction
• Designed for installation in compatible equipment and applications
• Installation should comply with applicable electrical codes and manufacturer requirements


Where It Works Best

• The THQB2140GF is often used in commercial buildings, industrial facilities, schools, offices, and other properties that utilize compatible Q-Line electrical distribution equipment. It works well in branch circuits serving HVAC systems, refrigeration equipment, lighting loads, and general power distribution, where a 40-amp, 2-pole ground-fault breaker is specified.
