THLC134090WL - 90Amp Circuit Breaker

THLC134090WL - 90Amp Circuit Breaker

The General Electric THLC134090WL is a premium 3-pole, 90-amp molded case circuit breaker designed for industrial and commercial power systems demanding high fault current protection and reliability. With an outstanding interrupting capacity of 200kA at 480VAC, this circuit breaker delivers superior safety and durability for electrical systems operating at up to 480 volts. The unit‰۪s current-limiting capability minimizes damage caused by fault currents, protecting both personnel and equipment. Equipped with line and load-side lugs and a non-interchangeable trip unit, it ensures dependable, seamless performance tailored to its specifications.

Key Features and Benefits

• Exceptional Interrupting Capacity: Rated at 200kA at 480VAC, providing robust protection in high-fault environments.
• Current-Limiting Design: Rapidly limits the let-through energy during fault events, reducing potential damage to electrical systems.
• Non-Interchangeable Trip Unit: Ensures the circuit breaker maintains its factory-calibrated performance without the risk of mismatched trip unit replacements.
• Inclusive Line and Load-Side Lugs: Simplifies installation with secure connection points, ensuring hassle-free setup for professionals.


Technical Specifications

• Frame Type: THLC1

• Poles: 3

• Amperage: 90A

• Voltage Rating: Up to 480VAC

• Interrupting Capacity: 200kA at 480VAC

• Dimensions:
  • Width: 4.13 inches
  • Length: 8.75 inches
  • Depth: 4.19 inches
• Weight: 16 lbs


Material Compliance and Certifications

• Manufactured in adherence to strict industry standards. The THLC134090WL is designed to comply with applicable UL certifications for molded case circuit breakers.

Suitability

• The THLC134090WL is ideal for critical applications in industrial plants, commercial buildings, and power distribution systems. Its high interrupting capacity and current-limiting features provide unmatched protection against severe electrical faults, making it a trusted solution for professionals seeking long-term reliability and safety. Its compact size and pre-installed line and load-side lugs further enhance its practicality for a variety of installations.
