THLC134090 - 90Amp Circuit Breaker

THLC134090 - 90Amp Circuit Breaker

The General Electric THLC134090 is a premium 3-pole, 90-amp molded case circuit breaker, expertly crafted to deliver top-tier protection in industrial and commercial applications. With its current limiting design and non-interchangeable trip unit, this circuit breaker ensures superior performance and safety by providing rapid response to electrical faults. Its robust construction and reliable operation make it an indispensable component for any high-demand power distribution system.

Key Features and Benefits

• Thermal Magnetic Trip Unit: The integrated thermal magnetic protection combines overload and short-circuit response, optimizing system safety.
• Load-Side Lugs Included: Features load-side lugs for secure, reliable connections, streamlining installation and maintenance processes.
• Bolt-On Mounting: The user-friendly bolt-on design simplifies installation, reducing labor time and cost.


Technical Specifications

• Frame Type: THLC1

• Poles: 3

• Amperage: 90A

• Voltage Rating: 480VAC

• Interrupting Capacity: 150kA at 480VAC, 200kA at 240VAC

• Dimensions: 4.13"W x 8.75"L x 4.19"D

• Ship Weight: 16 lbs


Material Compliance and Certifications

• Manufactured to meet stringent industry standards, the General Electric THLC134090 circuit breaker complies with top safety and performance regulations.

Suitability

• The THLC134090 is ideal for applications demanding high reliability and robust fault protection. From manufacturing facilities to commercial buildings, this circuit breaker‰۪s high interrupting capacity and durable design make it a perfect choice for environments requiring dependable, long-term electrical safety.
