THLC134080WL - 80Amp Circuit Breaker

THLC134080WL - 80 Amp Circuit Breaker

The THLC134080WL is an 80-amp, 3-pole current limiting circuit breaker designed for use in your commercial and industrial electrical distribution systems where dependable overcurrent protection is required. As part of the THLC1 series, this unfused circuit breaker features a non-interchangeable trip unit and is built to help protect your electrical equipment and conductors from damage caused by overloads and short circuits. With interrupting ratings of 150kA at 480VAC and 200kA at 240VAC, it is well-suited for installations where high fault current capacity is an important consideration. This breaker includes both line-side and load-side lugs, helping simplify installation and conductor termination. Its current-limiting design helps you to reduce the amount of fault energy that reaches downstream equipment during short-circuit events. Built for long service life in demanding electrical environments, the THLC134080WL is commonly used in switchboards, panelboards, motor control systems, and other power distribution applications requiring an 80A, 3-pole circuit breaker with high interrupting capability.

Key Features and Benefits

• 80 Amp current rating for commercial and industrial power distribution applications.
• 3-pole configuration for three-phase electrical systems.
• Current-limiting design helps reduce the impact of short-circuit events on connected equipment.
• Non-interchangeable trip unit provides fixed protection characteristics.
• Unfused construction for streamlined circuit protection applications.
• Includes line-side and load-side lugs for convenient installation.
• High interrupting capacity rated at 150kA @ 480VAC and 200kA @ 240VAC.
• Designed for compatibility with systems utilizing THLC1 series circuit breakers.
• Built to provide long-lasting service in demanding electrical environments.


Technical Specifications

• Part Number: THLC134080WL

• Series / Type: THLC1

• Current Rating: 80 Amps

• Number of Poles: 3

• Voltage & Interrupting Rating: 150kA @ 480VAC; 200kA @ 240VAC

• Breaker Type: Current Limiting Circuit Breaker

• Construction: Unfused

• Trip Unit: Non-Interchangeable

• Included Accessories: Line-Side and Load-Side Lugs

• Dimensions:
  • Height: 8.75 in.
  • Width: 4.13 in.
  • Depth: 4.19 in.

Material Compliance and Certifications

• Manufactured for use in electrical power distribution applications in accordance with applicable industry standards for molded case circuit breakers.
• Current-limiting breaker design is intended to support equipment protection during overcurrent and short-circuit conditions.
• Users should verify all application requirements, installation conditions, and local code compliance prior to use.


Where It Works Best

• The THLC134080WL is commonly used in commercial buildings and facilities, industrial manufacturing environments, power distribution equipment, switchboards and panelboards, motor control and feeder circuits, facilities requiring a high-interrupting capacity circuit protection, and electrical systems utilizing THLC1 series breaker configurations. Its combination of an 80A rating, 3-pole design, current-limiting protection, and high fault interruption capability makes it a practical choice for maintaining protection and continuity within existing electrical distribution systems where matching ratings, dimensions, and application requirements are essential.
