THLC134070 - 70Amp Circuit Breaker

THLC134070 - 70Amp Circuit Breaker

The THLC134070 is a robust 3-pole, unfused, current-limiting circuit breaker designed to ensure maximum safety and reliability in demanding industrial and commercial power systems. Built with a THLC1 frame type and equipped with a non-interchangeable trip unit, and it offers superior fault current interrupting capacity. Its 70-ampere rating makes it an ideal choice for applications requiring high-current handling with minimal space requirements.

Key Features and Benefits:

• Exceptional Fault Protection: With a fault current interrupting capacity of 200k AIC at 240VAC and 150k AIC at 480VAC, this breaker provides robust safety in high-demand environments.
• Current Limiting Technology: Limits energy let-through during fault conditions, protecting equipment from damage.
• Ease of Installation: Pre-equipped with load-side lugs to simplify and expedite setup.


Technical Specifications:

• Poles: 3

• Amperage: 70A

• Voltage Ratings: 480VAC (150k AIC), 240VAC (200k AIC)

• Frame Type: THLC1

• Weight: 16 lbs

• Trip Unit: Non-interchangeable

• Lugs: Load-side included


Material Compliance and Certifications:

• Premium Materials: The THLC134070 is manufactured with high-grade materials that meet rigorous industry standards for durability, safety, and performance.
• Regulatory Compliance: Complies with all relevant regulations, making it a dependable choice for professional installations.


Suitability:

• This circuit breaker is tailored for industrial and commercial applications that demand high fault current interrupting capacity and reliable circuit protection. It is ideal for use in panelboards, switchboards, and motor control centers, ensuring safety and stability in power distribution systems. Its 70A rating and current-limiting capabilities make it perfect for environments with high power requirements and sensitive equipment.


Durable, efficient, and built for performance, the THLC134070 delivers superior safety and protection for critical power systems.
