THLC134050 - 50Amp Circuit Breaker

THLC134050 - 50 Amp Circuit Breaker

The THLC134050 is a 50-amp, 3-pole current-limiting circuit breaker used in your commercial and industrial power distribution systems where high fault-current protection is required. Built with a non-interchangeable trip unit and an unfused design, this breaker helps provide consistent overcurrent protection while limiting the energy released during short-circuit conditions.

With interrupting ratings of 150kA at 480VAC and 200kA at 240VAC, the THLC134050 is intended for applications where available fault current levels demand a breaker capable of handling substantial interruption requirements. The breaker includes load-side lugs and is designed to fit compatible equipment utilizing the THLC1 frame.

Whether you installed in switchgear, distribution equipment, or other three-phase electrical systems, the THLC134050 delivers the form, fit, and function needed to keep existing equipment operating as intended. Its durable construction reflects the long service life expected from this style of circuit protection equipment and makes it a practical choice when maintaining established electrical infrastructure.

Key Features and Benefits

• 50 Amp Continuous Current Rating: 50 Amp continuous current rating.
• 3-Pole Configuration: 3-pole configuration for three-phase applications.
• Current Limiting Design: Current limiting design helps reduce short-circuit energy.
• Non-Interchangeable Trip Unit: Non-interchangeable trip unit.
• Unfused Construction: Unfused construction.
• Includes Load-Side Lugs: Includes load-side lugs.
• High Interrupting Capacity: Interrupting capacity of 150kA at 480VAC.
• High Interrupting Capacity: Interrupting capacity of 200kA at 240VAC.
• THLC1 Compatibility: Designed for use in compatible THLC1 applications.
• Long-Term Service: Built for long-term service in commercial and industrial environments.


Technical Specifications

• Part Number: THLC134050

• Type: THLC1

• Amperage: 50A

• Poles: 3

• A.I.C. Rating: 150kA @ 480VAC; 200kA @ 240VAC

• Configuration: Current Limiting

• Trip Unit: Non-Interchangeable

• Fuse Type: Unfused

• Included Accessories: Load-Side Lugs

• Dimensions:
  • Height: 8.75 in.
  • Width: 4.13 in.
  • Depth: 4.19 in.

Material Compliance and Certifications

• Industry Standards: This circuit breaker was manufactured to meet applicable industry standards associated with its original design and intended use.
• Verification Requirements: Verification of specific certifications, approvals, and code requirements should be made before installation, based on the application and jurisdiction.


Where It Works Best

• The THLC134050 is commonly found in commercial facilities, industrial plants, manufacturing operations, and other power distribution environments that utilize compatible THLC1 equipment. It is particularly suitable for maintaining existing systems where matching electrical ratings, physical dimensions, and connection requirements are important.
