THLC134040WL - 40Amp Circuit Breaker

THLC134040WL - 40 Amp Circuit Breaker

The THLC134040WL is a 40-amp, 3-pole Type THLC1 circuit breaker with a non-interchangeable trip unit and current-limiting design. This breaker is rated for 150kA at 480VAC and 200kA at 240VAC, making it suitable for your applications where high available fault current is present. The unit is supplied with both line-side and load-side lugs and is designed for installation in compatible electrical distribution equipment.

Current-limiting breakers are commonly used to help reduce the amount of fault current that passes through a system during a short circuit. The THLC134040WL provides overcurrent protection while maintaining the original form and fit required for equipment designed to accept Type THLC1 breakers. Its compact dimensions make it suitable for use in a variety of commercial and industrial power distribution applications.

Key Features and Benefits

• Part Number: THLC134040WL
• Type: THLC1 circuit breaker
• 40 amp rating
• 3-pole configuration
• Current-limiting design
• Non-interchangeable trip unit
• Unfused construction
• Includes line-side and load-side lugs
• 150kA interrupting rating at 480VAC
• 200kA interrupting rating at 240VAC


Technical Specifications

• Part Number: THLC134040WL

• Type: THLC1

• Amperage: 40A

• Poles: 3

• A.I.C. Rating: 150kA @ 480VAC; 200kA @ 240VAC

• Configuration: Unfused Current Limiting Circuit Breaker

• Trip Unit: Non-Interchangeable

• Included Accessories: Line-Side and Load-Side Lugs

• Dimensions:
  • Height: 8.75 in.
  • Width: 4.13 in.
  • Depth: 4.19 in.

Material Compliance and Certifications

• Application Information: This circuit breaker was manufactured for use in electrical power distribution systems. Users should confirm all application requirements, certifications, and code compliance requirements based on the installation, equipment, and local regulations.


Where It Works Best

• The THLC134040WL is commonly used in commercial and industrial electrical systems that require a 40-amp, 3-pole current-limiting circuit breaker. Typical applications include switchboards, panelboards, distribution equipment, and other compatible power distribution assemblies designed for Type THLC1 breakers.
