THLC134040 - 40Amp Circuit Breaker

THLC134040 - 40 Amp Circuit Breaker

The THLC134040 is a 40-amp, 3-pole current-limiting circuit breaker designed for use in your electrical distribution systems that require dependable overcurrent protection and high interrupting capacity. Built with a non-interchangeable trip unit, this unfused breaker helps you to protect conductors and connected equipment from overloads and short circuits while maintaining consistent trip characteristics. Its current-limiting design helps reduce the amount of fault energy that passes through the electrical system during short-circuit events, thereby protecting downstream equipment. Engineered for applications requiring high fault-current ratings, the THLC134040 features interrupting capacities of 150 kA at 480 VAC and 200 kA at 240 VAC. The breaker includes load-side lugs for simplified installation and is housed in a compact footprint suitable for a variety of commercial and industrial power distribution environments. Built to last and designed to provide dependable circuit protection, this breaker serves as a form, fit, and functional replacement for compatible Type THLC1 applications.

Key Features and Benefits

• 40 Amp Current Rating: Provides branch and feeder circuit protection for applications requiring a 40 amp breaker.
• 3-Pole Configuration: Designed for use in three-phase electrical systems.
• Type THLC1 Design: Built as a Type THLC1 circuit breaker for compatible applications.
• Current-Limiting Construction: Helps reduce fault energy during short-circuit conditions, protecting downstream equipment.
• Non-Interchangeable Trip Unit: Provides fixed trip characteristics for consistent protection performance.
• Unfused Configuration: Simplifies system configuration while maintaining dependable circuit protection.
• Load-Side Lugs Included: Allows convenient field installation and connection.
• High Interrupting Capacity:
  • 150kA at 480VAC
  • 200kA at 240VAC
• Compact Dimensions: Helps accommodate existing equipment layouts and installation requirements.
• Form, Fit, and Functional Replacement: Suitable for use in compatible systems requiring a Type THLC1 breaker.

Technical Specifications

• Part Number: THLC134040

• Type: THLC1

• Amperage Rating: 40 Amps

• Poles: 3

• Voltage Rating: 240VAC / 480VAC

• Interrupting Capacity: 200kA @ 240VAC

• Interrupting Capacity: 150kA @ 480VAC

• Circuit Breaker Style: Current Limiting

• Trip Unit: Non-Interchangeable

• Fuse Configuration: Unfused

• Included Accessories: Load-Side Lugs

• Dimensions:
  • Height: 8.75 in.
  • Width: 4.13 in.
  • Depth: 4.19 in.

Material Compliance and Certifications

• Industry Requirements: The THLC134040 is manufactured for use in electrical power distribution applications and is designed to meet applicable industry requirements associated with its original product category and ratings.
• Verification Recommended: Users should verify all installation requirements, certifications, and compliance standards applicable to their specific equipment and project specifications before installation.


Where It Works Best

• The THLC134040 is commonly used in commercial, industrial, and institutional electrical systems where high interrupting capacity and reliable overcurrent protection are required. Typical applications include:
  • Distribution panels and switchgear
  • Manufacturing facilities
  • Commercial buildings
  • Processing plants
  • Utility-related installations
  • Large electrical infrastructure projects
  • Three-phase power distribution systems requiring 40 Amp protection
  Its combination of compact dimensions, current-limiting design, and high fault-current ratings makes it well-suited for installations where space, protection requirements, and compatibility with existing equipment are important considerations.
