THLC134020 - 20Amp Circuit Breaker

THLC134020 - 20 Amp Circuit Breaker

The THLC134020 is a 3-pole, 20-amp current limiting circuit breaker designed for use in your electrical distribution systems where dependable overcurrent protection and high interrupting capacity are required. Built with a non-interchangeable trip unit, this unfused circuit breaker helps you to protect equipment and electrical circuits from damage caused by overloads and short circuits. Its current-limiting design reduces the amount of fault energy that passes through the system during fault conditions, helping protect connected components.

Featuring interrupting capacities of 150 kA at 480 VAC and 200 kA at 240 VAC, the THLC134020 is well-suited for applications where high fault current levels may be present. The breaker includes load-side lugs for straightforward installation and secure conductor termination. Designed for long service life and dependable operation, this breaker is commonly used in commercial and industrial electrical systems requiring a compact, high-capacity protective device.

Key Features and Benefits

• 20 amp current limiting circuit breaker: 20 amp current limiting circuit breaker.
• 3-pole configuration for three-phase electrical systems: 3-pole configuration for three-phase electrical systems.
• High interrupting capacity: Rated at 150kA @ 480VAC and 200kA @ 240VAC.
• Non-interchangeable trip unit: Helps maintain consistent protection settings.
• Unfused design: Simplifies system configuration.
• Includes load-side lugs: For secure electrical connections.
• Current-limiting technology: Helps reduce fault energy during short-circuit events.
• Compact footprint: For installation in compatible electrical equipment.
• Built for long-term service: In demanding electrical environments.


Technical Specifications

• Part Number: THLC134020

• Type: THLC1

• Poles: 3

• Amperes: 20A

• A.I.C. Rating @ 480VAC: 150kA

• A.I.C. Rating @ 240VAC: 200kA

• Dimensions:
  • Height: 8.75 in.
  • Width: 4.13 in.
  • Depth: 4.19 in.
• Trip Unit: Non-Interchangeable

• Configuration: Unfused Current Limiting Circuit Breaker

• Terminations: Include Load-Side Lugs


Material Compliance and Certifications

• Industry Standards: The THLC134020 is manufactured for use in electrical power distribution applications and is designed to meet applicable industry standards associated with its ratings and intended use.
• Compliance Verification: Users should verify specific compliance, certification, and installation requirements based on the application, equipment specifications, and local electrical codes.


Where It Works Best

• The THLC134020 is commonly used in commercial facilities, industrial plants, manufacturing environments, power distribution systems, motor control applications, and other electrical installations where a 20A, 3-pole current limiting circuit breaker is required. It is particularly suitable for systems with high available fault current levels where a current-limiting breaker can help protect downstream equipment and maintain system integrity.
