THHQL21125 - 125A Circuit Breaker

THHQL21125 125A Circuit Breaker

Introducing the THHQL21125 Circuit Breaker, a top-tier solution from ABB designed to deliver unparalleled performance and reliability for both residential and commercial applications. This circuit breaker is part of the renowned Q-Line series, known for its compact, one-inch per pole design, making it an ideal choice for spaces where efficiency and reliability are paramount. With a 125 Amp capacity and an interrupting capacity rating of 22 kAIC, the THHQL21125 ensures robust protection against electrical faults, enhancing safety and performance in any electrical setup.

Key Features and Benefits:

• Compact Design: The THHQL21125 boasts a one-inch wide per pole construction, making it a space-saving solution perfect for various installations.
• High Interrupting Capacity: With a 22 kAIC interrupting rating, this circuit breaker can handle significant fault currents, ensuring your system is well-protected.
• Thermal-Magnetic Protection: Combines both thermal and magnetic trip functionalities for comprehensive protection against overloads and short circuits.
• Quick-Make/Quick-Break Mechanism: Provides rapid response to electrical faults, minimizing damage and enhancing safety.
• Easy Installation: As a plug-in type breaker, it offers straightforward installation into load centers and lighting panels, reducing downtime and labor costs.

Technical Specifications:

• Voltage: 120/240V
• Amperage: 125A
• Interrupting Capacity: 22 kAIC at 120/240V
• Poles: 2
• Trip Style: Non-Interchangeable
• Frame Type: Q-Line
• Suitable for Reverse Feed: Yes
• UL File Number: E11592

Material Compliance and Certifications:

• The THHQL21125 circuit breaker meets rigorous safety and performance standards, ensuring compliance with UL (Underwriters Laboratories) certification. This certification attests to the product's quality and reliability, making it a trusted component in any electrical system. Additionally, it is designed for use in HACR (Heating, Air Conditioning, and Refrigeration) applications, showcasing its versatility and robustness.

Suitability:

• The THHQL21125 is engineered for both residential and commercial environments. Its compact size, combined with its high interrupting capacity and reliable thermal-magnetic protection, makes it an excellent choice for protecting electrical circuits in homes, offices, and industrial settings. Whether you need a reliable circuit breaker for a new installation or an upgrade to enhance the safety of your existing electrical system, the THHQL21125 is a superior choice.
