THHQB2190 - 90Amp Circuit Breaker

THHQB2190 - 90Amp Circuit Breaker

The THHQB2190 is a 90-amp, 2-pole thermal-magnetic miniature circuit breaker from the Q-Line series, designed to deliver reliable overcurrent protection in residential and commercial electrical systems. With a strong interrupting rating of 22kA at 120/240V, this breaker ensures safe and efficient circuit control and fault mitigation.

Key Features and Benefits:

• Thermal-Magnetic Protection: Provides long-time overload and short-time overcurrent protection, ensuring dependable circuit operation.
• Quick-Make/Quick-Break Mechanism: Enhances safety by responding swiftly to electrical faults, minimizing arc duration and damage.
• Compact Design: Only one inch wide per pole, ideal for maximizing space in load centers and panelboards.
• Bolt-On Mounting: Allows for easy, secure installation onto bus bars, reducing labor and installation time.
• Visible Trip Indicators: Enable quick visual detection of tripped circuits, aiding in fast diagnostics and reducing downtime.

Technical Specifications:

• Amperage: 90 A
• Poles: 2
• Voltage: 120V / 120/240V systems
• Interrupting Rating: 22 kAIC at 120/240V
• Trip Style: Non-Interchangeable
• Trip Function: LI (Long-Time and Instantaneous)
• Frame Type: Q-Line

Material Compliance and Certifications:

• UL Listed: Complies with UL safety standards (UL File #E11592)
• HACR Rated: Approved for Heating, Air Conditioning, and Refrigeration applications

Suitability:

• Residential Installations: Excellent for protecting home branch circuits and load centers.
• Commercial Applications: Ideal for use in commercial lighting panels and industrial equipment.
• Reverse Feed Compatible: Flexible installation allows for use in systems requiring reverse feed capability.
