THED136150 **Older Style** - 150 Amp Circuit Breaker

THED136150 **Older Style** - 150 Amp Circuit Breaker

The THED136150 Black Face Circuit Breaker is a 150-amp, three-pole industrial molded-case circuit breaker for your compatible commercial and industrial electrical distribution systems. Part of the THED series, this breaker features a non-interchangeable thermal-magnetic trip unit that provides overload and short-circuit protection within its specified electrical ratings. With interrupting capacities of 18kA at 600VAC, 25kA at 480VAC, and 65kA at 240VAC, the THED136150 offers clearly defined specifications for evaluating circuit protection requirements.

Key Features and Benefits

• 150-Amp Current Rating
• Three-Pole Circuit Breaker Configuration
• Thermal-Magnetic Trip Protection
• Non-Interchangeable Trip Unit
• Multiple AC Interrupting Ratings
• Distinctive Black-Face Design
• Load-Side Lugs Included
• Industrial Molded Case Construction
• THED Series Configuration

Technical Specifications

• Catalog Number: THED136150

• Product Type: Molded Case Circuit Breaker

• Product Category: Industrial Circuit Breaker

• Series / Type: THED

• Face Color: Black

• Rated Current: 150 Amperes (150A)

• Number of Poles: 3

• Trip Unit Type: Non-Interchangeable Thermal-Magnetic

• Overload Protection: Thermal

• Short-Circuit Protection: Magnetic

• Interrupting Capacity at 600VAC: 18,000 Amperes (18kA)

• Interrupting Capacity at 480VAC: 25,000 Amperes (25kA)

• Interrupting Capacity at 240VAC: 65,000 Amperes (65kA)

• Highest Specified AC Voltage: 600VAC

• Load-Side Lugs: Included

• Line-Side Lugs: Not specified in the supplied product information

• Height / Length: 6.31 Inches

• Width: 4.13 Inches

• Depth: 3.38 Inches

• Overall Dimensions: 4.13" W × 6.31" L × 3.38"D

• Approximate Shipping Weight: 6.50 lbs.

• UPC: 00783164135022


Material Compliance and Certifications

The THED136150 Black Face Industrial Circuit Breaker features molded case construction and a non-interchangeable thermal-magnetic trip unit. Its available specifications identify the principal electrical ratings, physical dimensions, and supplied load-side terminal connections.

Where It Works Best

• Existing Commercial Electrical Systems
• Industrial Power Distribution Equipment
• Three-Phase Electrical Applications
• Industrial Machinery and Equipment Protection
• Facility Maintenance and Electrical Repairs
• Legacy Electrical Distribution Systems
• Matching THED Circuit Breaker Replacements
• Compatible 150-Amp Electrical Circuits
• Commercial and Industrial Electrical Restoration
• Electrical Assemblies Requiring Black-Face Breakers
