The THED136110WL Black Face Circuit Breaker is a 110-amp, three-pole molded-case industrial circuit breaker for your compatible commercial and industrial electrical systems. One particularly useful feature of the THED136110WL is its included line-side and load-side lugs, which help identify the terminal configuration needed for a compatible replacement. The breaker also features a distinctive black face and measures 4.13 inches wide, 6.31 inches long, and 3.38 inches deep. When properly installed, operated, and maintained within its specified conditions, the THED136110WL is built to last. It is intended for applications where preserving the original equipment's form, fit, and protective function is essential.

Key Features and Benefits

• 110-Amp Current Rating
• Three-Pole Circuit Breaker Configuration
• Thermal-Magnetic Trip Protection
• Non-Interchangeable Trip Unit
• Multiple AC Interrupting Ratings
• Distinctive Black-Face Design
• Line-Side and Load-Side Lugs Included
• Molded-Case Industrial Construction
• Defined Physical Dimensions
• THED Series Configuration
• Form, Fit, and Functional Replacement Considerations

Technical Specifications

• Catalog Number: THED136110WL

• Product Type: Molded-Case Circuit Breaker

• Product Category: Industrial Circuit Breaker

• Series / Type: THED

• Face Color: Black

• Rated Current: 110 Amperes (110A)

• Number of Poles: 3

• Trip Unit Type: Non-Interchangeable Thermal Magnetic

• Thermal Protection Function: Overload Protection

• Magnetic Protection Function: Short-Circuit Protection

• Interrupting Capacity at 600VAC: 18,000 Amperes (18kA)

• Interrupting Capacity at 480VAC: 25,000 Amperes (25kA)

• Interrupting Capacity at 240VAC: 65,000 Amperes (65kA)

• Highest Specified AC Voltage: 600VAC

• Line-Side Lugs: Included

• Load-Side Lugs: Included

• Height / Length: 6.31 Inches

• Width: 4.13 Inches

• Depth: 3.38 Inches

• Dimensions: 4.13"W x 6.31"L x 3.38"D

• Approximate Shipping Weight: 6.50 lbs.

• UPC: 00783164143874


Material Compliance and Certifications

The THED136110WL industrial circuit breaker features molded-case construction and a non-interchangeable thermal-magnetic trip unit. Its electrical ratings and connection configuration are important considerations when determining suitability for an existing commercial or industrial installation.

Confirm material composition, product listings, and certification details through the individual breaker's markings and applicable manufacturer documentation.

Although the breaker has defined electrical specifications, these ratings do not independently establish a particular certification or approval. For installations requiring UL listing, CSA certification, or specific material compliance, verify the relevant markings and supporting documentation before use.

Where It Works Best

• Existing Commercial Electrical Systems
• Industrial Power Distribution Equipment
• Three-Phase Electrical Applications
• Industrial Machinery and Equipment Protection
• Facility Maintenance and Electrical Repairs
• Legacy Electrical Distribution Systems
• Matching THED Circuit Breaker Replacements
• Compatible 110-Amp Electrical Circuits
• Commercial and Industrial Electrical Restoration
• Electrical Assemblies Requiring Black-Face Breakers
• Applications Requiring Specified AC Interrupting Capacities
• Electrical Systems Using Line-Side and Load-Side Lug Connections
