THED136110 **Older Style** - 110 Amp Circuit Breaker

THED136110 **Older Style** - 110 Amp Circuit Breaker

The THED136110 Black Face Circuit Breaker is a 110-amp, three-pole molded-case industrial circuit breaker designed for compatible commercial and industrial electrical systems. The distinctive black-face design, combined with its included load-side lugs, makes the THED136110 a specific configuration to consider when matching an existing breaker. Whether you're maintaining industrial machinery or servicing an established commercial electrical distribution system, start by verifying the correct catalog number, amperage, trip characteristics, and connection arrangement to select a suitable replacement.

Key Features and Benefits

• 110-Amp Current Rating
• Three-Pole Configuration
• Thermal-Magnetic Protection
• Non-Interchangeable Trip Unit
• Specified AC Interrupting Capacities
• Load-Side Lugs Included
• Molded-Case Construction
• THED Series Configuration
• Form, Fit, and Functional Replacement

Technical Specifications

• Catalog Number: THED136110

• Product Type: Molded-Case Circuit Breaker

• Product Category: Industrial Circuit Breaker

• Series / Type: THED

• Face Color: Black

• Rated Current: 110 Amperes (110A)

• Number of Poles: 3

• Trip Unit Type: Non-Interchangeable Thermal Magnetic

• Overload Protection: Thermal

• Short-Circuit Protection: Magnetic

• Interrupting Capacity at 600VAC: 18,000 Amperes (18kA)

• Interrupting Capacity at 480VAC: 25,000 Amperes (25kA)

• Interrupting Capacity at 240VAC: 65,000 Amperes (65kA)

• Highest Specified AC Voltage: 600VAC

• Load-Side Lugs: Included

• Line-Side Lugs: Not specified as included

• Height: 6.31 Inches

• Width: 4.13 Inches

• Depth: 3.38 Inches

• Dimensions: 4.13"W x 6.31"H x 3.38"D

• Approximate Shipping Weight: 6.50 lbs.

• UPC: 00783164071016


Material Compliance and Certifications

The THED136110 is a molded-case industrial circuit breaker with a non-interchangeable thermal-magnetic trip unit and specified AC interrupting ratings.

Verify specific listings, certifications, and material compliance claims using the product markings and the manufacturer's technical documentation.

Where It Works Best

• Existing Commercial Electrical Systems
• Industrial Power Distribution
• Three-Phase Electrical Applications
• Industrial Machinery and Equipment
• Facility Maintenance and Electrical Repairs
• Legacy Electrical Distribution Systems
• Matching THED Circuit Breaker Replacements
• Compatible 110-Amp Electrical Circuits
• Commercial and Industrial Equipment Restoration
• Electrical Assemblies Requiring Black-Face Breakers
• Applications with Defined Fault-Current Requirements
• Load-Side Lug Connection Applications
