THED136100WL **Older Style** - 100 Amp Circuit Breaker

THED136100WL **Older Style** - 100 Amp Circuit Breaker

The THED136100WL Black Face Circuit Breaker is a 100-amp, three-pole molded-case industrial circuit breaker designed for your compatible commercial and industrial electrical distribution systems. Equipped with a non-interchangeable thermal-magnetic trip unit, this THED breaker combines thermal overload and magnetic short-circuit protection in a single molded-case assembly. Its interrupting capacities are 18kA at 600VAC, 25kA at 480VAC, and 65kA at 240VAC, giving electricians and maintenance teams the information they need to evaluate the breaker against the system voltage and available fault current. Built to last in a properly installed and maintained electrical system, it is intended to preserve the required form, fit, and protective function in compatible installations.

Key Features and Benefits

• 100-Amp Current Rating
• Three-Pole Circuit Breaker Configuration
• Thermal-Magnetic Trip Protection
• Non-Interchangeable Trip Unit
• Multiple AC Interrupting Ratings
• Distinctive Black-Face Design
• Line-Side and Load-Side Lugs Included
• Molded-Case Industrial Construction
• Defined Physical Dimensions
• THED Series Configuration
• Form, Fit, and Functional Replacement Considerations

Technical Specifications

• Catalog Number: THED136100WL

• Product Type: Molded-Case Circuit Breaker

• Product Category: Industrial Circuit Breaker

• Series / Type: THED

• Face Color: Black

• Rated Current: 100 Amperes (100A)

• Number of Poles: 3

• Trip Unit Type: Non-Interchangeable Thermal Magnetic

• Overload Protection: Thermal

• Short-Circuit Protection: Magnetic

• Interrupting Capacity at 600VAC: 18,000 Amperes (18kA)

• Interrupting Capacity at 480VAC: 25,000 Amperes (25kA)

• Interrupting Capacity at 240VAC: 65,000 Amperes (65kA)

• Highest Specified AC Voltage: 600VAC

• Line-Side Lugs: Included

• Load-Side Lugs: Included

• Lug Configuration: Line and Load-Side Lugs Included

• Height: 6.31 Inches

• Width: 4.13 Inches

• Depth: 3.38 Inches

• Dimensions: 4.13"W x 6.31"L x 3.38"D

• Approximate Shipping Weight: 6.50 lbs.

• UPC: 00783164062878


Material Compliance and Certifications

The THED136100WL is identified as a molded-case industrial circuit breaker with a non-interchangeable thermal-magnetic trip unit. Its documented AC interrupting capacities are essential to determine whether the breaker meets a particular installation's electrical requirements.

Confirm specific certification and compliance claims using the breaker's markings and manufacturer documentation. Before installation, verify that the breaker is approved for the intended equipment and meets applicable electrical codes, conductor requirements, and system fault-current conditions.

Where It Works Best

• Existing Commercial Electrical Systems
• Industrial Power Distribution Equipment
• Three-Phase Electrical Applications
• Industrial Machinery and Equipment Protection
• Facility Maintenance and Electrical Repairs
• Legacy Electrical Distribution Systems
• Matching THED Circuit Breaker Replacements
• Compatible 100-Amp Electrical Circuits
• Commercial and Industrial Electrical Restoration
• Electrical Assemblies Requiring Black-Face Breakers
• Applications Requiring Specified AC Interrupting Capacities
• Electrical Systems Using Line and Load-Side Lug Connections
