THED136015 **Older Style** - 15Amp Circuit Breaker

THED136015 **Older Style** - 15Amp Circuit Breaker

The THED136015 Black Face Circuit Breaker is a 15-amp, three-pole molded-case industrial circuit breaker designed for your compatible commercial and industrial electrical distribution systems. Part of the ABB/GE THED E150 breaker family, this model features a non-interchangeable thermal-magnetic trip unit that provides overload and short-circuit protection. Its interrupting capacities are 18kAIC at 600VAC, 25kAIC at 480VAC, and 65kAIC at 240VAC, giving electrical professionals the information they need to evaluate its suitability for an existing installation.

Key Features and Benefits

• 15 Amp Current Rating
• Three-Pole Configuration
• Black Face Design
• Thermal-Magnetic Protection
• Non-Interchangeable Trip Unit
• Load-Side Lugs Included
• THED E150 Frame Family
• Molded-Case Construction
• Form, Fit, and Functional Replacement

Technical Specifications

• Catalog Number: THED136015

• Product Identification: Black Face

• Manufacturer / Product Family: ABB/GE THED

• Product Type: Molded-Case Circuit Breaker (MCCB)

• Breaker Type: THED

• Frame Family: E150

• Current Rating: 15 Amps

• Number of Poles: 3

• Trip Unit Type: Thermal Magnetic

• Trip Unit Configuration: Non-Interchangeable

• Interrupting Rating at 600VAC: 18kAIC (18,000 Amps)

• Interrupting Rating at 480VAC: 25kAIC (25,000 Amps)

• Interrupting Rating at 240VAC: 65kAIC (65,000 Amps)

• Face Configuration: Black Face

• Load-Side Lugs: Included

• Line-Side Lugs: Not specified as included

• Approximate Height: 6.31 inches

• Approximate Width: 4.13 inches

• Approximate Depth: 3.38 inches

• Overall Dimensions: 4.13"W × 6.31" H × 3.38"D

• Approximate Shipping Weight: 6.50 lbs.


Material Compliance and Certifications

We have not independently confirmed specific UL listing file numbers, CSA certification numbers, RoHS compliance declarations, or material composition certifications for the exact THED136015 Black Face configuration.

Where It Works Best

• Legacy Electrical Distribution Systems
• Commercial Electrical Equipment
• Industrial Electrical Applications
• Facility Maintenance
• Black-Face Breaker Replacements
• Three-Pole Circuit Applications
• 240VAC Applications
• 480VAC Applications
• 600VAC Applications
• Load-Side Lug Connections
• E150-Frame Equipment
