THED113030 **Older Style** - 30Amp Circuit Breaker

THED113030 **Older Style** - 30Amp Circuit Breaker

When you need to replace an industrial circuit breaker, finding the right match involves more than checking the amperage. The pole configuration, interrupting capacity, trip unit, physical dimensions, and terminal connections all matter. For electricians, electrical contractors, and facility maintenance professionals working with established THED systems, matching the original breaker's form, fit, and function helps preserve the equipment's intended configuration.

Key Features and Benefits

• 30-Amp, Single-Pole Configuration:
• 65 kAIC Interrupting Rating at 277VAC:
• Non-Interchangeable Thermal-Magnetic Trip Unit:
• Distinctive Black-Face Construction:
• Molded Case Industrial Design:
• Load-Side Lugs Included:
• Form, Fit, and Function Replacement:

Technical Specifications

• Catalog Number: THED113030

• Product Identification: THED113030 Black Face

• Product Type: Molded Case Industrial Circuit Breaker

• Breaker Type: THED

• Face Configuration: Black Face

• Amperage: 30 Amps

• Number of Poles: 1

• Interrupting Capacity: 65 kAIC at 277VAC

• Interrupting Rating in Amperes: 65,000 Amperes at 277VAC

• Trip Unit Type: Thermal-Magnetic

• Trip Unit Interchangeability: Non-Interchangeable

• Overload Protection: Thermal

• Short-Circuit Protection: Magnetic

• Load-Side Lugs: Included

• Line-Side Lugs: Not Specified in Supplied Product Information

• Terminal Arrangement: Load-Side Lugs Included

• Height: 6.31 inches

• Width: 1.38 inches

• Depth: 3.38 inches

• Overall Dimensions: 1.38" W × 6.31" H × 3.38" D

• Approximate Shipping Weight: 2.25 lbs.

• Intended Application: Compatible with Industrial Electrical Distribution Equipment


Material Compliance and Certifications

The THED113030 Black Face 30 Amp Circuit Breaker is a molded-case industrial circuit breaker with a specified 65 kAIC interrupting rating at 277 VAC. The supplied product information does not identify a specific UL file number, UL listing classification, CSA certification, or other certification reference.

Where It Works Best

• Legacy Industrial Electrical Systems:
• Existing THED Breaker Replacement:
• Commercial Electrical Distribution Equipment:
• Facility Maintenance and Electrical Repairs:
