TFJ236125 **Older Style** - 125Amp Circuit Breaker

TFJ236125 **Older Style** - 125Amp Circuit Breaker

The General Electric TFJ236125 is a robust 125-amp, 3-pole molded case circuit breaker designed for industrial applications requiring reliable overcurrent protection. With a maximum voltage rating of 600V AC, it ensures safety and efficiency in demanding electrical environments.

Key Features and Benefits:

• Thermal Magnetic Protection: Combines both long-time and instantaneous trip functions to safeguard against overloads and short circuits.
• Bolt-On Connection: Facilitates secure and straightforward installation, enhancing system integrity.
• Reverse Feed Capability: Suitable for reverse feed applications, offering installation flexibility.
• Load-Side Lugs Included: Comes equipped with load-side lugs, simplifying the connection process.

Technical Specifications:

• Amperage: 125A
• Poles: 3
• Voltage Rating: 600V AC
• Interrupting Capacity (AIC):
• 25kA at 240V AC
• 22kA at 480V AC
• 18kA at 600V AC
• Frame Type: TFJ
• Dimensions: 4.13 inches (W) x 10.13 inches (L) x 3.81 inches (D)
• Ship Weight: 10 lbs

Material Compliance and Certifications:

• Manufactured by General Electric, a leader in electrical components, the TFJ236125 adheres to industry standards, ensuring quality and reliability.
• It complies with relevant UL, CSA, NOM, and IEC standards, meeting stringent safety and performance criteria.

Suitability:

• Ideal for industrial settings, the TFJ236125 is engineered to handle high-demand electrical systems, providing dependable protection and operational stability.
• Its thermal magnetic trip unit and molded case design make it suitable for various applications, including manufacturing plants, commercial buildings, and other facilities requiring robust circuit protection.

Incorporating the General Electric TFJ236125 into your electrical infrastructure ensures enhanced safety, reliability, and performance, making it a valuable addition to any industrial power distribution system.
