TFJ224080WL **Older Style** - 80Amp Circuit Breaker

TFJ224080WL **Older Style** - 80Amp Circuit Breaker

The TFJ224080WL is a 2-pole, 80 amp Type TFJ molded case circuit breaker with an older style black face. Built as part of the F225 line, this breaker uses a non-interchangeable thermal magnetic trip unit to provide overload and short-circuit protection in compatible electrical systems. It includes both line-side and load-side lugs, making it ready for installation in equipment designed for this breaker style.

If you're replacing an existing TFJ breaker, matching the original specifications is important. The TFJ224080WL offers an 80 amp rating, a 22kA interrupting rating at 480VAC, and 25kA at 240VAC, helping maintain the original electrical design of compatible panels and switchgear. Built to last, this breaker is intended as a form, fit, and functional replacement for existing installations where the same type, ratings, and physical dimensions are required.

Key Features and Benefits

• Type TFJ Molded Case Circuit Breaker: Type TFJ molded case circuit breaker.
• Older Style Black Face: Older Style Black Face.
• 80 Amp Continuous Current Rating: 80 amp continuous current rating.
• 2-Pole Design: 2-pole design.
• Non-Interchangeable Thermal Magnetic Trip Unit: Non-interchangeable thermal magnetic trip unit.
• F225 Line Molded Case Breaker: F225 line molded case breaker.
• Includes Line-Side and Load-Side Lugs: Includes line-side and load-side lugs.
• Built to Last: Built to last in properly maintained electrical systems.
• Form, Fit, and Functional Replacement: Designed as a form, fit, and functional replacement for compatible equipment.

Technical Specifications

• Part Number: TFJ224080WL
• Type: TFJ
• Product Family: F225 Line
• Poles: 2
• Amperage: 80 Amps
• Trip Unit: Thermal Magnetic
• Trip Unit Style: Non-Interchangeable
• Interrupting Rating: 22kA @ 480VAC
• Interrupting Rating: 25kA @ 240VAC
• Dimensions:
  • Height: 10.13 in.
  • Width: 4.13 in.
  • Depth: 3.81 in.
• Lugs: Line and Load Side Included
• Face Style: Older Style Black Face

Material Compliance and Certifications

• Manufacturing: Manufactured to the original product specifications for compatible applications.
• Application: Designed for use in equipment requiring a Type TFJ molded case circuit breaker.
• Installation: Confirm the breaker type, ampere rating, voltage, interrupting capacity, and physical configuration before installation.

Where It Works Best

• The TFJ224080WL is commonly found in commercial buildings, industrial facilities, manufacturing plants, and power distribution equipment that use Type TFJ F225 molded case circuit breakers. It is a practical choice for replacing an existing breaker with the same ratings and configuration while maintaining compatibility with the original electrical system.
