TFJ224070WL **Older Style** - 70Amp Circuit Breaker

TFJ224070WL **Older Style** - 70Amp Circuit Breaker

The TFJ224070WL is a 2-pole, 70-amp molded case circuit breaker with an Older Style Black Face and a fixed thermal magnetic trip unit. It is designed for use in your compatible TFJ electrical distribution equipment where the original breaker style and ratings need to be maintained. The breaker uses a non-interchangeable trip unit and comes with both line-side and load-side lugs already included. Whether you're replacing a failed breaker or servicing existing equipment, matching the correct frame, interrupting rating, and trip characteristics helps you to keep the electrical system operating as intended. Like many industrial molded case breakers from this series, it was built for long service life in demanding electrical applications.

Key Features and Benefits

• TFJ224070WL part number
• Older Style Black Face design
• 2-pole configuration
• 70 Amp current rating
• Fixed thermal magnetic trip unit
• Non-interchangeable trip unit
• Includes line-side and load-side lugs
• Designed for use in compatible TFJ applications

Technical Specifications

• Part Number: TFJ224070WL
• Type: TFJ
• Frame: F225 Line Molded Case
• Poles: 2
• Amperage: 70 Amps
• Trip Unit: Thermal Magnetic, Non-Interchangeable
• Interrupting Rating:
  • 22kA @ 480VAC
  • 25kA @ 240VAC
• Dimensions:
  • Height: 10.13 in.
  • Width: 4.13 in.
  • Depth: 3.81 in.
• Included: Line-side and Load-side Lugs

Material Compliance and Certifications

• This molded case circuit breaker is intended for use in compatible electrical distribution equipment. Before installation, verify that the breaker's ratings, frame, and configuration match the equipment manufacturer's requirements. Installation should be completed by qualified personnel and in accordance with applicable electrical codes.

Where It Works Best

• The TFJ224070WL is commonly used in industrial facilities, commercial buildings, manufacturing plants, and electrical distribution systems that utilize compatible TFJ series circuit breakers. It is a practical choice for maintenance work, equipment repairs, and replacing an existing breaker with the same ratings and configuration.
