TEYL3125B - 125Amp Circuit Breaker

TEYL3125B - 125Amp Circuit Breaker

Elevate the safety and efficiency of your electrical systems with the TEYL3125B - TEYX Circuit Breaker, an essential component for modern electrical installations. This three-pole, 125A circuit breaker is engineered to provide exceptional performance and protection for grounded 480Y/277 Vac systems. Its compact, one-inch wide per pole design allows for space-efficient installations, making it a versatile solution for diverse electrical setups.

Key Features and Benefits:

• Bolt-On Installation: Ensures a secure and reliable connection, ideal for both new constructions and maintenance upgrades.
• Quick-Make/Quick-Break Mechanism: Minimizes response time, enhancing safety by quickly interrupting electrical flows during fault conditions.
• Common Trip Bars: Offers simultaneous tripping of all poles upon fault detection, providing comprehensive protection.
• Visible Trip Indicator: Easy identification of breaker status for prompt troubleshooting and maintenance.
• Versatile Accessory Compatibility: Supports auxiliary contacts, shunt trip, undervoltage release, and bell alarm accessories, adapting to various application needs.

Technical Specifications:

• Amperage: 125A
• System Voltage Compatibility: Can be used with systems up to 480/277 Vac.
• High Interrupting Ratings: 100 KAIC at 240 Vac and 65 KAIC at 480/277 Vac, ensuring durability and reliability under high fault conditions.
• Fixed Trip Functionality: Delivers consistent performance with fixed long-time and instantaneous functions.
• Wire Range: Accommodates #4 to 2/0 AWG copper or aluminum wires, providing flexibility in wiring.

Material Compliance and Certifications:

• UL Certification: The TEYL3125B circuit breaker meets stringent UL standards (UL File #E11592), ensuring it adheres to the highest safety and quality specifications.

Suitability:

• This circuit breaker is designed for reverse feed use, making it suitable for a variety of directional applications in both commercial and industrial environments. Whether integrated into lighting panels or used as a main breaker, its robust design and flexible features make it an ideal choice for ensuring electrical safety and compliance.

Enhance your electrical system's integrity with the TEYL3125B - TEYX Circuit Breaker, your reliable safeguard against electrical faults. Perfect for applications demanding high safety, adaptability, and uninterrupted service.
