TEYL3090B - 90A Circuit Breaker

TEYL3090B 90A Circuit Breaker

Unlock top-tier safety and efficiency with the TEYL3090B - TEYX Circuit Breaker 3P 90A, a standout choice for professionals and homeowners alike. Engineered to operate flawlessly in grounded 480Y/277 Vac systems, this compact, one-inch wide per pole, bolt-on circuit breaker is designed for robustness and versatility. Its installation simplicity, courtesy of the bolt-on mounting base, allows it to fit seamlessly into various setups as a lug-lug breaker, making it a reliable partner for both industrial and residential applications.

Key Features and Benefits:

• Quick-make/Quick-break Mechanisms: Enjoy instantaneous response with mechanisms that ensure swift disconnection during faults, enhancing protective measures.
• Common Trip Bars and Visible Trip Indication: Provides unified trip action for all poles and clear status acknowledgment, boosting system safety and maintenance efficiency.
• Modular Accessories: Available options include auxiliary contacts, shunt trip, undervoltage release, and bell alarms, catering to diverse electrical system requirements.

Technical Specifications:

• Amperage: 90A, allowing it to handle high current applications with ease.
• System Voltage Compatibility: Includes 120/240 Vac, 240 Vac, 250 Vdc, 277 Vac, and 480/277 Vac.
• Interrupting Ratings: Comes with varying ratings such as 100 KAIC at 120/240 Vac and 240 Vac, 42 KAIC at 125 Vdc, and 65 KAIC at 480/277 Vac, ensuring optimal protection.
• Trip Function: LI (Long-Time and Instantaneous), providing reliable circuit protection.
• Wire Range: Accommodates #4 to 2/0 size wires, offering flexibility in wiring options.

Material Compliance and Certifications:

• UL Listed (File #E11592): Ensuring compliance with stringent safety standards and reliability in diverse environments.

Suitability:

• Reverse Feed: Yes, for versatile application in different system configurations.
• Application Areas: Ideal for lighting panels in both commercial and residential buildings, ensuring safety and compliance with electrical standards.

Enhance your electrical infrastructure with the TEYL3090B - TEYX Circuit Breaker 3P 90A, where safety meets sophistication. Perfect for those who need reliable, high-performance solutions in their power management systems.
