TEYL3035B - 35Amp Circuit Breaker

TEYL3035B - 35 Amp Circuit Breaker

The TEYL3035B is a 35 Amp, 3-pole bolt-on circuit breaker designed for use in compatible 480Y/277V Class panelboards. It uses a thermal magnetic trip mechanism to protect electrical circuits from overloads and short circuits, making it a dependable option for your commercial and industrial power distribution.

With a 65kA interrupting rating at 480VAC and 100kA at 240VAC, this breaker is suitable for applications where higher available fault current is present. The fixed, non-interchangeable trip means the trip setting cannot be changed, helping you to maintain the intended level of protection after installation. The bolt-on mounting design provides a secure connection to the panel, making this breaker a common choice for replacements, repairs, and routine electrical maintenance.

Key Features and Benefits

• 35 Amp Current Rating: 35 Amp current rating.
• Three-Pole Design: Three-pole design for three-phase systems.
• Bolt-On Mounting: Bolt-on mounting.
• Thermal Magnetic Protection: Thermal magnetic protection against overloads and short circuits.
• Non-Interchangeable Trip Unit: Non-interchangeable factory-set trip unit.
• 65kA Interrupting Capacity: 65kA interrupting capacity at 480VAC.
• 100kA Interrupting Capacity: 100kA interrupting capacity at 240VAC.
• 480Y/277V Class Applications: Designed for 480Y/277V Class applications.


Technical Specifications

• Part Number: TEYL3035B

• Type: TEYL

• Amperage: 35A

• Poles: 3

• Trip Type: Thermal Magnetic

• Trip Unit: Non-Interchangeable

• Mounting: Bolt-On

• Voltage Class: 480Y/277V

• Interrupting Rating:
  • 65kA @ 480VAC
  • 100kA @ 240VAC
• Dimensions:
  • Height: 5.25 in.
  • Width: 3.00 in.
  • Depth: 3.06 in.

Material Compliance and Certifications

• Installation Requirements: This circuit breaker is intended for use in compatible electrical distribution equipment.
• Installation Guidance: Installation should be completed by qualified personnel in accordance with applicable electrical codes and the equipment manufacturer's requirements.


Where It Works Best

• The TEYL3035B is commonly installed in commercial buildings, industrial facilities, schools, office buildings, and other three-phase electrical systems. Typical applications include lighting panels, HVAC equipment, motor circuits, and general branch circuit protection.
