TEYL3030B - 30A Circuit Breaker

TEYL3030B 30A Circuit Breaker

Upgrade the safety and efficiency of your electrical system with the TEYL3030B - TEYX Circuit Breaker. This three-pole, 30A circuit breaker is engineered for superior performance on grounded 480Y/277 Vac systems, making it a versatile choice for a variety of commercial and industrial applications. Its one-inch wide per pole, compact design features a "bolt-on" mounting base that enhances its adaptability and ensures a reliable installation.

Key Features and Benefits:

• Quick-make / Quick-break Mechanism: Ensures swift and reliable circuit interruption, enhancing safety and reducing the risk of electrical fires.
• Common Trip Bars: Offers simultaneous tripping of all poles during overload conditions, ensuring complete disconnection for maintenance and safety.
• Trip Indication: Easily visible trip indication allows for quick identification of tripped circuits, simplifying troubleshooting and maintenance.

Technical Specifications:

• Amperage: 30A
• System Voltage: 120/240 Vac, 240 Vac, 250 Vdc, 277 Vac, 480/277 Vac
• Interrupting Ratings: 100 KAIC at 120/240 Vac, 100 KAIC at 240 Vac, 35 KAIC at 250 Vdc, 65 KAIC at 480/277 Vac
• Trip Function: LI (Long-Time and Instantaneous)
• Wire Range: #10-#4 (Copper/Aluminum)

Material Compliance and Certifications:

• This breaker is manufactured under strict quality standards to ensure durability and reliability. It is UL listed under File #E11592, guaranteeing compliance with safety regulations and performance standards.

Suitability:

• Ideal for lighting panel circuit breakers and compatible with TEY / Q-Line (Bolt-On) product lines. The TEYL3030B is also suitable for reverse feed use, providing flexibility and ease of use in various installation scenarios.

Designed for robust performance and reliability, the TEYL3030B circuit breaker is a top choice for ensuring the safety and efficiency of electrical installations in commercial and industrial buildings. Explore more about this product and its capabilities to see why it is the preferred choice for professionals across various industries.
