TEYL3025B - 25Amp Circuit Breaker

TEYL3025B - 25Amp Circuit Breaker

Upgrade your electrical systems with the TEYL3025B 3‑pole circuit breaker—engineered for top-tier safety, performance, and flexibility in both commercial and industrial settings. Whether you're outfitting a lighting panel or a heavy-duty motor control center, this breaker has you covered with superior protection and ease of installation.

Key Features and Benefits

• Compact yet powerful design: At just 1" per pole, this breaker offers a full 25 A capacity without sacrificing panel space.
• Reliable trip response: Quick‑make and quick‑break mechanisms deliver fast reaction to electrical faults—minimizing risk and downtime.
• Clear trip status: Built-in common trip bars and visible indicators make it effortless to detect and reset tripped circuits.
• Adaptable with accessories: Customize for your needs—add auxiliary contacts, shunt trips, undervoltage releases, or bell alarms.
• Flexible mounting: Bolt‑on base allows easy integration into a variety of electrical panels and load centers.

Technical Specifications

• Amperage: 25 A
• Poles: 3‑pole
• System Voltages: 120/240 Vac, 240 Vac, 250 Vdc, 277 Vac, 480Y/277 Vac
• Interrupting Ratings:
  • 100 kAIC @ 240 Vac
  • 65 kAIC @ 480/277 Vac
• Trip Functions: Fixed Long Time & Instantaneous (LI)
• Wire Range: #10–#4 CU/AL

Material Compliance and Certifications

• UL‑listed (E11592): Fully compliant with UL safety standards, giving you peace of mind when installing in high-stakes environments.

Suitability

• This breaker shines in commercial and industrial settings where durability and dependable circuit protection are critical—think:
  • Office lighting and power distribution
  • HVAC and refrigeration systems
  • Control panels and machine wiring
  • Reverse‑feed applications thanks to its adaptable design
