TEYL3020B - 20Amp Circuit Breaker

TEYL3020B - 20Amp Circuit Breaker

Upgrade your electrical safety and efficiency with the TEYL3020B 20A 3 Pole 65KA Circuit Breaker, a top-tier solution designed for grounded 480Y/277V systems. Engineered for reliability, this compact, bolt-on circuit breaker features a width of just one inch per pole, making it an ideal choice for space-saving installations.

Key Features and Benefits:

• Robust Protection: Offers a high interrupting rating of 65KAIC at 480/277V, ensuring excellent protection against overcurrents and short circuits.
• Versatile Mounting: The bolt-on design allows for stable, secure installation and is suitable for a variety of applications, from commercial to industrial.
• Quick-make/Quick-break Mechanism: Enhances safety and reliability through immediate disconnection under fault conditions.
• Visible Trip Indicator: Makes it easy to identify tripped circuits, simplifying troubleshooting and maintenance.
• Optional Accessories: Can be customized with auxiliary contacts, shunt trip, undervoltage release, or bell alarm features, catering to specific needs.

Technical Specifications:

• Amperage: 20A
• Poles: 3
• Voltage: Up to 480/277V
• Interrupting Rating: 65KAIC
• Frame Type: TEYL
• Trip Function: LI (Long-Time and Instantaneous)
• Wire Range: #14-#10 Cu/Al

Material Compliance and Certifications:

• UL Listed: Ensures compliance with rigorous safety standards (UL File #E11592).
• Suitable for Reverse Feed: Offers flexible installation options.

Suitability:

• Designed for commercial and industrial environments, this circuit breaker is particularly suited for lighting panel applications. It ensures consistent performance and safety with its fixed long-time and instantaneous trip functions.
