TEYL3015B - 15A Circuit Breaker

TEYL3015B 15A Circuit Breaker

Discover superior circuit protection with the TEYL3015B - TEYX Circuit Breaker 3P 15A, an essential component for modern electrical safety. Designed for high-demand environments, this three-pole circuit breaker ensures consistent performance and reliability. With its bolt-on design, the TEYL3015B is perfect for grounded 480Y/277 Vac systems, providing a compact, space-saving solution without compromising on power.

Key Features and Benefits:

• Robust Protection: The TEYL3015B offers a high interrupting rating, handling up to 100 KAIC at 120/240 Vac and 65 KAIC at 480/277 Vac, making it suitable for high-energy applications.
• Quick-make / Quick-break Mechanisms: Ensures rapid response to faults, minimizing potential damage and downtime.
• Trip Indication: Easy-to-spot trip indication allows for fast diagnostics and reduced maintenance time.
• Versatile Mounting: Bolt-on mounting makes this breaker adaptable for various installation scenarios.

Technical Specifications:

• Poles: 3
• Amperage: 15A
• System Voltage: Up to 480/277 Vac
• Interrupting Ratings: Diverse ratings across various voltages, including 100 KAIC at 240 Vac and 35 KAIC at 250 Vdc.
• Trip Function: LI (Long-time and Instantaneous)

Material Compliance and Certifications:

• UL File # E11592: Certified safety and compliance to rigorous standards, ensuring a reliable and secure operation in residential and commercial structures.

Suitability:

• Suitable for Reverse Feed: Yes, providing flexibility in system design and wiring.
• Wire Range: #14-#10, accommodating standard wiring sizes for straightforward integration into existing systems.

The TEYL3015B circuit breaker is not just a component; it's a safeguard for your electrical systems, ensuring efficiency and safety are always a top priority. Whether you're upgrading your existing panel or installing new electrical infrastructure, the TEYL3015B brings peace of mind with its exceptional features and dependable performance.
