TEYH3100B - 100Amp Circuit Breaker
TEYH3100B - 100Amp Circuit Breaker
Couldn't load pickup availability
TEYH3100B - 100Amp Circuit Breaker
When you replace a circuit breaker in an existing electrical panel, the right fit matters as much as the correct amperage. The mounting arrangement, voltage rating, interrupting capacity, and conductor connections must match the equipment you're servicing. The ABB TEYH3100B Circuit Breaker is a 100-amp, 3-pole, bolt-on lighting panel circuit breaker from the ABB TEY / Q-Line family. Built around the TEYH frame, this compact breaker features a one-inch-per-pole design for compatible commercial and industrial electrical distribution systems.
Key Features and Benefits
- 100-Amp, 3-Pole Configuration:
- Multiple Interrupting Capacity Ratings:
- Fixed Long-Time and Instantaneous Protection:
- Quick-Make / Quick-Break Mechanism:
- Compact Bolt-On Construction:
- Reverse-Feed Suitability:
- Form, Fit, and Function Replacement:
Technical Specifications
-
Manufacturer: ABB
-
Catalog Number: TEYH3100B
-
Product Type: Lighting Panel Circuit Breaker
-
Product Line: TEY / Q-Line (Bolt-On)
-
Frame Type: TEYH
-
Manufacturer Description: TEYX Circuit Breaker, 3-Pole, 100A
-
Amperage: 100 Amps
-
Number of Poles: 3
-
Mounting Style: Bolt-On
-
Nominal Width Per Pole: 1 inch
-
System Voltages Listed by Manufacturer: 120/240VAC, 240VAC, 250VDC, 277VAC, and 480/277VAC
-
Interrupting capacity at 120/240VAC: 65 kAIC
-
Interrupting Capacity at 240VAC: 65 kAIC
-
Interrupting capacity at 480/277VAC: 35 kAIC
-
Trip Function: LI (Long-Time and Instantaneous)
-
Long-Time Trip Setting: Fixed
-
Instantaneous Trip Setting: Fixed
-
Operating Mechanism: Quick-Make / Quick-Break
-
Trip Indication: Visible Trip Indication
-
Common Trip Bar: Yes
-
Continuous Current Rating Classification: Standard
-
Suitable for Reverse Feed: Yes
-
Wire Range (Copper/Aluminum): #4–2/0 AWG
-
Current Metering: No
-
Protective Relays: No
-
GSA Compliance: No
-
UL File Number: E11592
-
GO Schedule: EY
-
Environmental Product Declaration: No Declaration Needed
-
UPC: 783164462234
Material Compliance and Certifications
The ABB TEYH3100B 100 Amp Circuit Breaker is associated with UL File E11592, providing a manufacturer-supplied reference for verifying applicable UL certification information.
Where It Works Best
- Legacy Electrical Panel Maintenance:
- Commercial Lighting Panelboards:
- Industrial Electrical Distribution:
- Existing TEY / Q-Line Breaker Replacement:
