TEYH3090B - 90Amp Circuit Breaker
TEYH3090B - 90Amp Circuit Breaker
Couldn't load pickup availability
TEYH3090B - 90Amp Circuit Breaker
Finding the right circuit breaker for your existing electrical panel means getting the details right. Amperage matters, but so do the mounting arrangement, voltage requirements, interrupting capacity, and physical configuration. The ABB TEYH3090B Circuit Breaker is a 90-amp, 3-pole, bolt-on lighting panel circuit breaker from the ABB TEY / Q-Line family. Featuring a compact, one-inch-per-pole design and a TEYH frame, it is intended for compatible commercial and industrial electrical distribution systems. Whether you're replacing a breaker in an established lighting panel or maintaining an existing electrical installation, the TEYH3090B offers a practical option when you must preserve the original form, fit, and electrical function.
Key Features and Benefits
- 90-Amp, 3-Pole configuration:
- Multiple Interrupting Capacity Ratings:
- Fixed Long-Time and Instantaneous Protection:
- Quick-Make / Quick-Break Mechanism:
- Compact Bolt-On Construction:
- Reverse-Feed Suitability:
Technical Specifications
-
Manufacturer: ABB
-
Catalog Number: TEYH3090B
-
Product Type: Lighting Panel Circuit Breaker
-
Product Line: TEY / Q-Line (Bolt-On)
-
Frame Type: TEYH
-
Manufacturer Description: TEYX Circuit Breaker, 3-Pole, 90A
-
Amperage: 90 Amps
-
Number of Poles: 3
-
Mounting Style: Bolt-On
-
Nominal Width Per Pole: 1 inch
-
System Voltages Listed by Manufacturer: 120/240VAC, 240VAC, 250VDC, 277VAC, and 480/277VAC
-
Interrupting capacity at 120/240VAC: 65 kAIC
-
Interrupting Capacity at 240VAC: 65 kAIC
-
Interrupting capacity at 480/277VAC: 35 kAIC
-
Trip Function: LI (Long-Time and Instantaneous)
-
Long-Time Trip Setting: Fixed
-
Instantaneous Trip Setting: Fixed
-
Operating Mechanism: Quick-Make / Quick-Break
-
Trip Indication: Visible Trip Indication
-
Common Trip Bar: Yes
-
Continuous Current Rating Classification: Standard
-
Suitable for Reverse Feed: Yes
-
Wire Range (Copper/Aluminum): #4–2/0 AWG
-
Current Metering: No
-
Protective Relays: No
-
GSA Compliance: No
-
UL File Number: E11592
-
GO Schedule: EY
-
Environmental Product Declaration: No Declaration Needed
-
UPC: 783164462227
Material Compliance and Certifications
The ABB TEYH3090B 90 Amp Circuit Breaker is identified under UL File E11592, providing a manufacturer-supplied reference for evaluating its applicable UL certification information.
Where It Works Best
- Legacy Electrical Panel Maintenance:
- Commercial Lighting Panelboards:
- Industrial Electrical Distribution:
- Existing TEY / Q-Line Breaker Replacement:
