TEYH3030B - 30Amp Circuit Breaker

TEYH3030B - 30 Amp Circuit Breaker

The TEYH3030B is a 30 Amp, 3-pole bolt-on thermal magnetic circuit breaker for use in your compatible 480Y/277V Class electrical distribution equipment. It combines thermal overload protection with magnetic short-circuit protection and uses a non-interchangeable trip unit with a fixed trip setting.

This breaker has an interrupting rating of 35kA at 480VAC and 65kA at 240VAC. The bolt-on design provides a secure connection to the panel, making it suitable for replacement work as well as new installations where a TEYH breaker is specified.

Key Features and Benefits

• 30 Amp rating
• Three-pole configuration
• Bolt-on mounting
• Thermal magnetic trip mechanism
• Non-interchangeable trip unit
• 35kA interrupting rating at 480VAC
• 65kA interrupting rating at 240VAC
• Built for 480Y/277V Class applications


Technical Specifications

• Part Number: TEYH3030B

• Type: TEYH

• Poles: 3

• Current Rating: 30 Amps

• Trip Type: Thermal Magnetic

• Trip Unit: Non-Interchangeable

• Mounting: Bolt-On

• Voltage Class: 480Y/277V

• Interrupting Rating: 35kA @ 480VAC; 65kA @ 240VAC

• Dimensions:
  • Height: 5.25 in.
  • Width: 3.00 in.
  • Depth: 3.06 in.

Material Compliance and Certifications

• Installation: Verify that this breaker matches the panelboard and application before installation.
• Requirements: Installation should be completed in accordance with applicable electrical codes and the equipment manufacturer's requirements. Product markings provide the applicable ratings and certifications.


Where It Works Best

• The TEYH3030B is used in compatible commercial and industrial panelboards serving three-phase electrical systems. Typical applications include lighting panels, HVAC equipment, motor loads, and general branch circuit protection.
