TEYF3050B - 50A Circuit Breaker

TEYF3050B 50A Circuit Breaker

Introducing the TEYF3050B Circuit Breaker, a versatile and reliable solution designed to meet the demanding requirements of modern electrical systems. With its Quick-make / Quick-break mechanisms, common trip bars, and easy-to-spot trip indication, this breaker guarantees superior safety and operational reliability. Perfect for a wide range of commercial and industrial settings, the TEYF3050B is designed to deliver outstanding performance and peace of mind.

Key Features and Benefits:

• Compact and Efficient Design: The one-inch width per pole allows for efficient use of space, making it suitable for diverse applications.
• Enhanced Safety Features: Equipped with Quick-make / Quick-break mechanisms, common trip bars, and clear trip indicators to ensure maximum safety and reliability.
• Versatile Installation: The bolt-on mounting base ensures a secure and adaptable installation process, suitable for various applications as a lug-lug breaker.
• Wide Application Range: Ideal for use on 480Y/277 Vac systems, with availability in 1, 2, and 3 pole versions and optional auxiliary contact and shunt trip accessories.

Technical Specifications:

• Poles: 3
• Amperage: 50 A
• System Voltage: 120/240 Vac, 240 Vac, 277 Vac, 480/277 Vac
• Frame Type: TEYF
• Interrupting Rating: 65 KAIC at 120/240 Vac, 65 KAIC at 240 Vac, 18 KAIC at 277 Vac, 18 KAIC at 480/277 Vac
• Trip Style: Non-Interchangeable
• Trip Function: LI (Long Time/Instantaneous)
• Continuous Current Rated: Standard
• Suitable for Reverse Feed: Yes
• Wire Range (Cu/Al): #10-#4

Material Compliance and Certifications:

• Compliance: The TEYF3050B Circuit Breaker complies with rigorous industry standards, ensuring high performance and dependability. It is UL listed and CSA certified, offering assurance of its quality and adherence to safety regulations. These certifications underscore its suitability for a wide range of demanding electrical applications, ensuring reliable and safe operation.

Suitability:

• The TEYF3050B Circuit Breaker is perfectly suited for use in a variety of commercial and industrial environments, particularly in lighting panel applications. Its robust construction and versatile mounting options make it an excellent choice for both new installations and retrofit projects. Designed to meet the highest standards of safety and performance, the TEYF3050B provides the reliability and protection needed for critical electrical systems.
