TEYD3060B - 60Amp Circuit Breaker

TEYD3060B - 60Amp Circuit Breaker

Optimize your electrical systems with the TEYD3060B - TEYX Circuit Breaker, a robust solution engineered for grounded 480Y/277 Vac systems. This 3-pole, 60A bolt-on circuit breaker offers a streamlined, one-inch per pole profile designed for easy installation and integration into various applications. The TEYD3060B excels in safety and reliability, featuring a Quick-make / Quick-break mechanism that enhances operational efficiency, and a common trip bar that ensures simultaneous disconnection of all poles during a trip event.

Key Features and Benefits:

• Compact Design: Ideal for space-constrained environments, this breaker's one-inch wide per pole construction allows for dense panel configurations without sacrificing performance.
• Enhanced Safety Mechanisms: Equipped with easy-to-spot trip indication to swiftly identify fault conditions, enhancing safety and ease of maintenance.
• Versatile Mounting Options: The bolt-on mounting base simplifies installation across various settings, making it an adaptable choice for both new builds and retrofit applications.

Technical Specifications:

• Poles: 3
• Amperage: 60 A
• System Voltage Options: 120/240 Vac, 240 Vac, 250 Vdc, 277 Vac, 480/277 Vac
• Interrupting Rating: 65 KAIC at 240 Vac, 25 KAIC at 480/277 Vac
• Trip Function: LI (Long-Time and Instantaneous)

Material Compliance and Certifications:

• UL Listed (File #E11592), ensuring compliance with rigorous safety standards.

Suitability:

• Reverse Feed: Yes, suitable for reverse feed applications, providing flexibility in system design.
• Wiring: Accommodates wire sizes from #10 to #4 AWG (Copper/Aluminum), facilitating various installation needs.

This circuit breaker is an essential component for professionals seeking reliable and efficient electrical protection solutions. Its robust construction and flexible installation options make it a prime choice for industrial applications, ensuring continuity and safety of your electrical systems.
