TEYD3050B - 50Amp Circuit Breaker
TEYD3050B - 50Amp Circuit Breaker
Couldn't load pickup availability
TEYD3050B - 50Amp Circuit Breaker
Secure your electrical systems with the TEYD3050B - TEYX Circuit Breaker, a robust and reliable solution engineered for performance and safety. This 3-pole circuit breaker, with a 50A current rating, is specifically designed for use in grounded 480Y/277 Vac systems, ensuring compatibility with a broad range of industrial applications. The TEYD series offers a bolt-on mounting feature that facilitates easy installation and a solid connection, reducing the risk of disconnection under load.
Key Features and Benefits:
- Compact Design: At just one-inch wide per pole, this circuit breaker is designed to save space in your electrical panel, allowing for efficient use of your system's capacity.
- Quick-make/Quick-break Mechanisms: These features ensure rapid response to faults, significantly enhancing safety by reducing the duration of electrical arcs.
- Common Trip Bars: Provide simultaneous tripping of all poles on a fault occurrence, ensuring complete disconnection and enhancing protective measures.
- Visible Trip Indicator: Makes it easy to identify tripped circuits, facilitating quick diagnostics and reducing downtime.
- Versatility: Certified for reverse feed use, making it suitable for a variety of directional current applications.
Technical Specifications:
- Amperage: 50A
- System Voltage Compatibility: Includes 120/240 Vac, 240 Vac, 250 Vdc, and 277 Vac, up to 480/277 Vac systems.
- Interrupting Ratings: Offers high interrupting ratings of 65 KAIC at 240 Vac and 25 KAIC at 480/277 Vac, enhancing the breaker's fault handling capacity.
- Wire Range: Accommodates #10-#4 AWG copper or aluminum wires, providing flexibility in connection options.
Material Compliance and Certifications:
- UL Listed (File E11592): Ensures compliance with stringent safety standards, enhancing trust and reliability.
- Suitability for Various Environments: Ideal for both commercial and industrial applications, meeting the diverse needs of modern electrical systems.
Suitability:
- Perfect for installation in lighting panels, the TEYD3050B circuit breaker supports a wide array of applications from commercial buildings to industrial facilities. Its bolt-on feature makes it a preferred choice for systems that require a permanent, secure installation.
Enhance your electrical system's safety and reliability with the TEYD3050B - TEYX Circuit Breaker, your trusted partner in electrical management and protection. Designed for both flexibility and performance, this circuit breaker is an essential component for any serious electrical infrastructure.
